Medical trolley wheel Integral twin

for hospital bedfor operating tablepolyamide

Product description The Integral twin swivel castor features a solid stem, round fitting (32 mm) for secure mounting in medical equipment. The housing is manufactured from medium-grade steel sheet and uses a precision ball bearing swivel system for smooth directional changes. The wheel assembly comprises a polyamide body with an injected polyurethane tread and precision ball bearings for optimal rolling performance.

The wheel diameter is 4.92 in (125 mm) and the overall height of the assembly is 5.91 in (150 mm). Load ratings: dynamic 275.58 lb (≈125 kg) at 1.86 mph (3 km/h) and 2.49 mph (4 km/h); static load capacity 826.73 lb (≈375 kg). Temperature range: -13 °F to 176 °F (-25 °C to 80 °C). Designed for demanding medical environments including anesthesia carts, imaging devices and hospital beds.

Key features

• Non-hazardous materials
• Tested quality (tested and monitored by TÜV Süd)
• Award-winning design
• Solid housing (pressed steel, zinc plated)
• Low-maintenance wheels with thread guards
• Non-marking movement
• Chemical-resistant components
• Certified safety
• Optimised manoeuvrability (twin-wheel differential effect)

Applications

• Anesthesia carts
• C-arms
• CT scanners
• MRI equipment
• X-ray equipment
• Care beds / Hospital beds
• Surgery robots
• Surgery tables
• Ultrasound devices
• Hospitals, nursing homes and retirement facilities

Technical data / specifications

• Article Number: 2940UAP125R05-32 9002 M6/7
• EAN: 4031582302493
• S4 Material Number: 990033737
• Series / Product name: Integral twin
• Type: Swivel castor
• Wheel diameter: 4.92 in (125 mm)
• Overall height: 5.91 in (150 mm)
• Overall width: 2.48 in (63 mm)
• Overall weight: 2.59 lb (≈1.18 kg)
• Load capacity (dynamic) at 3 km/h: 275.58 lb (≈125 kg)
• Load capacity (dynamic) at 4 km/h: 275.58 lb (≈125 kg)
• Load capacity (static): 826.73 lb (≈375 kg)
• Load capacity (dynamic) examples: 275.58 lb at 1.86 mph and 275.58 lb at 2.49 mph
• Tread material: Polyurethane, injected
• Body material (wheel): Polyamide
• Tread hardness: 92 Shore A / 42 Shore D
• Tread width / Body width: 0.47 in (12 mm)
• Bearing (wheel): Precision ball bearing
• Swivel bearing: Precision ball bearing
• Threadguards: With threadguard
• Housing material: Steel sheet, medium
• Housing color: Gray white (RAL9002)
• Fork shape: Twin wheel housing
• Offset: 1.48 in (38 mm)
• Swivel radius: 4.06 in (103 mm)
• Dome diameter: 2.42 in (61.5 mm)
• Swivel interference: 8.11 in (206 mm)
• Fitting type: Solid stem, round (32 mm)
• Bolt mounting holes quantity: 2
• Bolt diameter: 1.26 in (32 mm)
• Bolt length: 1.77 in (45 mm)
• Bolt thread position: 0.28 in (7 mm)
• Temperature range: -13 °F to 176 °F (-25 °C to 80 °C)
• Standard: EN12531 - Hospital Bed Castors
• Certification: Tested and monitored by TÜV Süd
• Electric conductive: No
• Stainless: No
