Medical device battery TIP1

compact

Overview
TiMOTION TIP1 is a 120W AC-to-DC power supply designed to deliver a constant 24V DC output for actuators and motion systems. It accepts 90–305V AC input, achieves up to 93.5% conversion efficiency, and uses passive cooling to minimize noise. The metal housing and IP67 rating enable indoor or outdoor installations in ventilated conditions. Operational temperature: -40°C to +85°C.

Key points

• Constant 24V DC output
• Input voltage: 90–305V AC
• Output power: 120W (24V, max 5A)
• Conversion efficiency up to 93.5%
• Fanless design (low noise)
• Ingress protection: IP67 for dust and water resistance

General Features

• Topology: SMPS (switch-mode power supply)
• Plugs supported: EU, USA, AUS, UK, JPN
• Certifications: BIS, UL8750, TUV, PSE, CCC, ENEC, CB, EMC, CE, UKCA
• Operating temperature: -40°C to +85°C
• Housing: metal appearance suitable for industrial use

Standard Dimension (mm)
Refer to the product dimension diagram for exact mechanical dimensions.

Technical specifications

• Model: TIP1 Series
• Rated power: 120W
• Output: 24V DC, up to 5A
• Input: 90–305V AC
• Efficiency: up to 93.5%
• Cooling: fanless (passive)
• Ingress protection: IP67
• Operating temperature: -40°C to +85°C
