Medical thermosealer TRRA 7001for the pharmaceutical industryfor productionlaboratory
Add to favorites
Compare this product
Characteristics
- Applications
- medical, for the pharmaceutical industry, for production, laboratory
- Operation
- automatic
- Configuration
- in-line
- Options
- with temperature control
- Seal width
Min.: 5 mm
(0 in)Max.: 30 mm
(1 in)- Sealing speed
Min.: 0 mm/min
(0 in/s)Max.: 11,000 mm/min
(7 in/s)- Sealing temperature
Min.: 80 °C
(176 °F)Max.: 220 °C
(428 °F)
Description
Product
Key features
Technical specifications
Applications
Options & ordering
- TRRA 7001 heating sealer for bag sealing in sterile areas
Key features
- Epoxy-coated metal construction suitable for use in sterile environments
- Flexible production: available in different designs and dimensions
- User-friendly control panel with digital screen
- Digital temperature control (adjustable 80°C – 220°C)
- Supports bags 5 mm – 30 mm wide
- Adjustable seal distance
- Automatic in-feed with optical sensor
- Automatic standby and automatic shut-off modes
- Automatic overheat protection
- Sealing speed up to 11 m/min
- Complies with DIN 58953-7
Technical specifications
- Material: Epoxy-coated metal (suitable for sterile areas)
- Temperature range: 80°C – 220°C (digital thermometer)
- Display: Digital screen
- Bag width supported: 5 mm – 30 mm
- Seal distance: Adjustable
- Feeding: Automatic in-feed with optical sensor
- Operational modes: Automatic standby; automatic overheat protection; automatic shut-off device
- Sealing speed: 11 m/min
- Standards: Conforms to DIN 58953-7
- Production options: Custom designs and dimensions available
Applications
- Designed for sealing bags in medical, pharmaceutical and laboratory sterile environments
- Suitable for integration into packaging and production lines
- Appropriate for small-format sterile bag sealing and sampling bags
Options & ordering
- Available customization of dimensions and design to match production requirements
- Specify control and interface options at order
- Contact supplier for datasheet, spare parts and maintenance support
