Sensor protection tube ZPT-SPT-002

stainless steel

Sensor Protection Tube by ZorayPT
ZorayPT’s sensor protection tube is a precision stainless steel housing designed to shield sensitive sensors from mechanical load, chemical exposure and contaminants in medical, laboratory and industrial sensing applications. Offered as a sleeve or encapsulation tube, it preserves measurement integrity and extends service life. Production capabilities include tube drawing, CNC machining, laser processing and mirror polishing.

Construction and Performance
Manufactured from medical-grade AISI 316/316L stainless steel (AISI 304 available), with inner diameters from 0.15 mm to 3.4 mm and fully customizable lengths. Standard wall thickness is 0.1 mm, configurable down to 0.05 mm to reduce sensor interference while maintaining structural strength. Inner and outer surfaces are mirror-polished to minimize friction and adhesion. The 316/316L grade provides enhanced corrosion resistance in saline and aggressive environments.

Customizable Processing Options
Available operations include slotting, bending, flaring, necking, chamfering, flat or rounded tip formation, perforations for fluid exchange, or solid-wall variants for complete sealing. All geometries and features can be produced to engineering drawings or physical samples.

Manufacturing & Packaging
ZorayPT delivers full in-house manufacturing from raw material selection to final finishing, enabling rapid prototyping and scalable production. Packaging options include individual blister packing or bulk packaging per customer requirements.

Key Features

• Inner Diameter: 0.15 mm – 3.4 mm (customizable)
• Wall Thickness: 0.05 mm – 0.1 mm (customizable)
• Length: fully customizable
• Material: medical-grade AISI 316/316L (304 available)
• Processing: slotting, bending, flaring, tip shaping, perforation or solid-wall options
• Mirror-polished inner and outer surfaces
• Ultra-thin walls to minimize sensor interference

Applications

• Medical device sensing: protection for temperature, pressure and invasive probes
• Environmental monitoring: protection for water quality and soil sensors
• Industrial process control: transducer housings for harsh environments

Why Choose ZorayPT?

• One-stop in-house manufacturing for consistent quality control
• ISO 13485 certified production environment (Class 100,000 cleanroom)
• Capability to produce medical-grade stainless steel housings with precision finishing
• Automated and scalable production enabling reduced lead times

Specifications

• Product Model: ZPT-SPT-002
• Inner Diameter: 0.15 mm – 3.4 mm (customizable)
• Wall Thickness: 0.05 mm – 0.1 mm (customizable)
• Length: fully customizable
• Material: AISI 316 / 316L (304 available)
• Processing: slotting, bending, flaring, tip shaping, perforation, solid-wall
• Applications: medical, environmental, industrial sensor protection
