Description
The BeautyScan™ is the high-end laser system to perform the fractional Non-ablative Skin Resurfacing. It utilizes state-of-the-art technology and provides a 1550nm fiber Er-Glass laser module to achieve optimal results in non-invasive treatment of scars, stretch marks and wrinkles.

Principle of operation
The BeautyScan™ transmits the 1550nm laser energy into the skin to produce thousands of tiny microthermal zones and create small microscopic columns of thermal injury to the skin. It stimulates the body’s own wound healing response which produces new collagen and refreshes the outer layer of the skin (epidermis).

Clinical Applications

• Acne Scars
• Stretch marks
• Other scars (Burn, Surgical and other scars)
• Wrinkles removal
• Aging wrinkles
• Rough skin
• Coarse pore

Features

• Non-ablative, painless & bloodless solution
• Targeted treatment without side effects
• Short treatment times & quick recovery time
• Comfort and excellent satisfaction rate reported by patients

Key advantages

• Stable: The BeautyScan™ adopts 1550nm fiber Er-Glass laser module technology to provide a stable wavelength, uniform spot size and accurate performance during treatment.
• Excellent ease of use: User friendly software and intelligent design assist the user to choose the optimal treatment settings.
• Flexibility and Versatility: Diversified scanning modes and spot sizes meet different treatment needs.
• Cost Effective: No costly consumable, no costly maintenance.

Specifications
Laser type: Fiber Er-Glass laser
Wavelength: 1550nm ±1nm
Output power: 1-10W
Operation mode: Fractional
Figure filling: 9% – 100%
Treatment Surface Area: 1mm-16mm Adjust
Spot Size: 100um
Pulse width: Ton: 1ms-50ms Toff: 1ms-5000ms
Pulse repetition rate: 0Hz – 500Hz
Application systems: Scanner
Transmission system: fibers and collimator
Aiming beam: Diode laser of 635nm, power <5mW, adjustable brightness
Operation interface: 10.2’ Color LCD touch screen
Laser Class: 4
Safety classification: Class I Type B
Cooling: Air
Dimensions: 400(W) * 400(L) * 950(H) mm
Weight: 35kg
Waterproof level: IPX1
Footswitch Waterproof level: IPX8
Safety Compliance: IEC

Caractéristiques / spécifications techniques

• Laser type: Fiber Er-Glass laser
• Wavelength: 1550nm ±1nm
• Output power: 1-10W
• Operation mode: Fractional
• Figure filling: 9% – 100%
• Treatment Surface Area: 1mm-16mm adjustable
• Spot Size: 100 µm
• Pulse width: Ton 1ms-50ms; Toff 1ms-5000ms
• Pulse repetition rate: 0Hz – 500Hz
• Application systems: Scanner
• Transmission system: Fibers and collimator
• Aiming beam: 635nm diode laser, <5mW, adjustable brightness
• Operation interface: 10.2" color LCD touch screen
• Laser Class: 4
• Safety classification: Class I Type B
• Cooling: Air
• Dimensions: 400 × 400 × 950 mm (W×L×H)
• Weight: 35 kg
• Waterproof level: IPX1 (device)
• Footswitch Waterproof level: IPX8
• Safety compliance: IEC
