Urological examination chair AGA-URO-MED

electricTrendelenburgheight-adjustable

Overview The AGA urology examination chairs are designed for clinical use with functional equipment and electrical adjustments where specified. They provide adjustable working heights, a seat cutout and integrated gyroscopic sink for urology procedures.

Models

• AGA-URO-MAT — Article No.: UUS-3060/EEE
• AGA-URO-LIFT — Article No.: UUS-3060/EE
• AGA-URO-MED — Article No.: UUS-3058/E

Product description All three models are intended for urology examinations. Each chair includes an electric motor for seat-section adjustment. AGA-URO-MED has a fixed height; AGA-URO-MAT and AGA-URO-LIFT feature electric height adjustment (650–850 mm). On AGA-URO-MAT the backrest adjustment is electric. Working heights can reach up to approx. 1,160 / 1,175 mm (measured at the front edge of the seat). Upholstery is ergonomically shaped with an integrated foam wedge in the backrest and a cutout in the seat section.

Features

• AGA-URO-MAT and AGA-URO-LIFT: electric height adjustment 650–850 mm with precision double square guides to prevent lateral offset.
• AGA-URO-MED: seat cushions accessible via a fold-away footstep mounted on the floor frame; tread in polyethylene with non-slip surface.
• Trendelenburg position up to 30° via seat elevation and adjustable back section.
• Back section adjustment to +54°: electric on AGA-URO-MAT; gas spring on AGA-URO-LIFT and AGA-URO-MED.
• Maintenance-free, low-noise electric drives controlled by foot switch (hand control available as option); adjustment systems with key locks.
• Floor frame with levelling feet for secure stand; impact- and scratch-resistant covers easy to clean and disinfectant resistant.
• Different upholstery thicknesses (seat 85 mm; backrest 85–135 mm) with coordinated foam densities for seating comfort.
• Standard stainless steel side rails (25 x 10 mm, length 350 mm) for leg support systems.
• Integrated gyroscopic sink (330 x 300 x 100 mm) moving in parallel with seat elevation; supplied with siphon, hoses, tap with aerator and backflow preventer (DIN EN 1717), flushing nozzle.
• Earthing socket on back of column for equipment connection (e.g. colposcope).

Standard version includes

• Pair of standard side rails
• Right/left supports for colposcope holder
• Earthed socket on column rear
• Seat cushion cutout
• Parallel gyroscopic sink
• Paper roll holder screwed to back section
• Floor frame with levelling feet
• Foot switch(es) (hand control optional)
• Fold-away footrest (AGA-URO-MED only)

Technical details

• Article numbers: AGA-URO-MAT = UUS-3060/EEE | AGA-URO-LIFT = UUS-3060/EE | AGA-URO-MED = UUS-3058/E
• Frame: lacquered; finish disinfectant-resistant (standard colours available)
• Length (back/seat sections): 1,150 mm; back/seat 800 / 350 mm
• Width: 580 mm (640 mm with standard rails)
• Height adjustment (AGA-URO-MAT / AGA-URO-LIFT): 650–850 mm (electric)
• Working height up to approx. 1,160 / 1,175 mm (measured at front edge of seat)
• Seat section adjustment: +30° (electric)
• Backrest adjustment: 0° to +54°
• Trendelenburg adjustment: up to 30°
• Upholstery thickness: seat 85 mm; backrest 85–135 mm; 2 upholstery segments
• Cutout in seat cushion: yes
• Standard rails: stainless steel 25 x 10 mm, length 350 mm
• Gyroscopic sink: 330 x 300 x 100 mm including siphon, hoses, tap with aerator and backflow preventer (DIN EN 1717)
• Load capacity: 200 kg
• Motor connection values (each): 230 V, 50/60 Hz, 3.7 A, 850 W, IPX4; speed 11 mm/s; force 10,000 N

Accessories & additional options (selection)

• BH-2511 Leg rests (pair) with plastic shells, chrome rods, Velcro straps
• BHG-600 Göpel leg rests (pair) with spherical joints and PU supports
• BKG-600 Göpel fastening clamps (pair) for standard rails (Ø 18 mm rods)
• BKO-2522 Fastening clamps (pair) with clamping handle
• BP-460 Leg plate to insert under seat section, cushion 580 x 350 mm
• FES-2000 Heel supports (pair)
• FUS-2000 Footrests (pair) with synthetic leather cover, non-slip coating
• GBH-2000 Göpel leg holders (pair) with ball joints and straps
• KP-1058 Knee plate to insert under seat cushion
