Medical sterilizer AX-60

laboratorydentalfor the pharmaceutical industry

Compact tabletop EO sterilizer for clinics and laboratories

The AX‑60 is a fully automated ethylene oxide (EO) sterilization system with a 60-liter stainless-steel chamber. Designed for low-temperature sterilization of heat- and moisture-sensitive items, it is ideal for outpatient facilities, laboratories, and private clinics where space efficiency and safety are essential.

Applications:
Used to sterilize small-volume loads such as catheters, stents, endoscopes, dental and surgical tools, wound dressings, and other delicate materials that are sensitive to steam or high-temperature sterilization.

Product Advantages:

• 60 L stainless-steel chamber
• Fully automatic EO cycle: conditioning, gas exposure, sterilization, aeration
• EO cartridge-based gas exposure with liner bag and humidity chip for precise dosing and internal monitoring
• 7” color touchscreen for real-time cycle tracking and control
• USB port and optional printer for data documentation
• Safety features: door interlock, over-temperature, power failure, continuous negative pressure
• Bottom heating system and vacuum-sealed door
• Maintenance-free operation; no need for external air, water, or drainage
• Compact and easy-to-install countertop structure

Performance & Specifications:

• Capacity: 60 L
• Chamber size: 35×49×35 cm | Total size: 52×66×47 cm
• Power: 200 W | Voltage: 110–220 V | Amperage: 2 A
• Cycle duration: Approx. 1–27 hours depending on load
• Interface: 7” touchscreen + USB 2.0 + optional printer
• Structure: Countertop

Standards & Compliance:
Compliant with ISO 13485, EN 14937, EN 61010, EN 60601-1/2, MDR. Validation software available.
