Laboratory sonicator UCD-4000W-II

for molecular biologyprogrammablestainless steel

Application
The UCD-4000W-II is intended for continuous-flow disruption and homogenization of biological and chemical samples. Typical uses include cell and bacterial lysis, nanoparticle dispersion and emulsification for R&D, pilot lines and small-batch production.

Product overview
Brand: BIOBASE
Model: UCD-4000W-II
Product origin: CHINA
Delivery time: Within 7 days
Supply capacity: Factory direct supply

Key features

• Continuous-flow operation with selectable batch processing (500–10,000 ml per run).
• Adjustable ultrasonic power: 1000–4000 W.
• Frequency range: 19.5–20.5 kHz with automatic frequency tracking.
• LCD interface and storage for up to 20 program groups.
• Temperature monitoring and control for sample protection.
• Optional automatic feeding and computer control for integration into process lines.

Technical parameters

• Model: UCD-4000W-II
• Frequency: 19.5–20.5 kHz
• Ultrasonic power: 1000–4000 W (adjustable)
• Standard amplitude-change rod: Φ40×250 mm or Φ40×370 mm
• Batch capacity: 500–10,000 ml
• Continuous capacity: up to 100 L/day
• Operating modes: continuous or pulse (optional)
• Max. working time: 99 h 59 min 59 s
• Safety protections: over-temperature, timing, overload, no-load
• Power supply: AC220 V 50/60 Hz (standard); AC110 V 50/60 Hz (optional)
• Package size (W×D×H): 675×305×450 mm (main body); 430×415×730 mm (soundproof box)
• Gross weight: 32 kg

Accessories & options

• Standard accessories: main unit, energy converter, standard amplitude rod, sound-proof box (or support frame).
• Optional accessories: stainless-steel reactor, peristaltic pump, low-temperature water tank, automatic feeder, computer control interface.
