Rodent software SEDACOM

laboratoryfor preclinical researchfor biomedical research

Presentation

SEDACOM 2.0 is a data transfer and visualization software designed for direct acquisition, storage and export of experimental data from BIOSEB devices. It provides a centralized environment to monitor sessions, save recorded data and export results in common formats for post-processing and statistical analysis.

Operating principle

SEDACOM (SErial DAta COMmunication) communicates with BIOSEB instruments via RS232 serial ports; USB adapters are supported as optional accessories for laptop use. The software can acquire data from up to 9 devices simultaneously, limited by the number of available serial ports on the host computer. Users may add an external hub or serial port board (not included) to increase connections. SEDACOM automatically detects connected systems.

Parameters Measured

• Subject & Session data
• Numerical data tables with all values and parameters generated by BIOSEB devices

Domains of application

SEDACOM is compatible with multiple BIOSEB product lines for physiology and behavior measurements in small laboratory animals, including motor activity, nociception, temperature and memory tests. Typical compatible devices include:

• ELECTRONIC VON FREY
• HOT-PLATE
• IR ACTIMETER
• NON-INVASIVE BLOOD PRESSURE
• PASSIVE AVOIDANCE BOX
• PLETHYSMOMETER
• RAT PAW PRESSURE
• ROTA-ROD
• ROTAMETER
• SHUTTLE BOX
• TAIL-FLICK METER
• TREADMILL

Key features

• Multi-device acquisition and centralized data management
• RS232 serial communication with optional USB adapters
• Runtime panels with tabular layout to speed up post-analysis
• Editable Subject and Group fields for experiment organization
• Save data in experimental SED files and append additional sessions
• Direct export to Excel, .txt and .htm for processing and presentation
• Configure and control certain devices directly from SEDACOM (e.g. IR actimeter, Treadmill)
• USB installation with license key included
• Trial version available

Technical specifications

• Reference: SEDACOM
• Software version: SEDACOM 2.0
• Type: data transfer and visualization software
• Communication: RS232 serial port; optional USB adapters supported
• Max simultaneous devices: up to 9 (limited by available serial ports; additional hub/board not included)
• Automatic recognition of connected systems
• Data storage: saves and lists current or stored sessions
• File format: experimental file (.SED)
• Export formats: Excel, .txt, .htm
• Device control: configuration and control available for some devices (e.g. IR actimeter, Treadmill)
• Delivery: USB installation and license key
• Trial version: available
