Animal research biosignal acquisition system POPULAR

for teaching4-channelUSB

Presentation
The IX-214 is a physiology data acquisition unit housed in an extruded aluminum enclosure and configured for classroom and teaching-lab use. Controls are limited to essential student-accessible functions. With a single mouse click the unit can be set to record EEG, EMG (EOG) or ECG.

Acquisition channels and stimulation
The IX-214 includes a dual-channel biopotential amplifier suitable for human and rodent subjects plus two general-purpose input channels that accept pressure, temperature, force sensors and voltage outputs from laboratory instruments. A built-in stimulator supports human and animal labs; an optional high-voltage stimulus isolator expands stimulation capabilities.

Physiology Teaching Kits
BIOSEB provides combined Animal/Human Physiology Teaching Kits optimized for the IX-214. Kits include transducers and documentation to support a comprehensive lab course (standard packages cover up to 33 experiments and 123 exercises; with the high-voltage isolator kits support up to 34 experiments and 127 exercises). Systems can be configured by selecting sensors and software options.

System requirements
Minimum PC: Pentium II class (or equivalent) running Windows, >=64 MB RAM, >=10 MB free disk space. Internet connection required for free firmware and software upgrades.

Key hardware features

• Three-year unconditional hardware warranty.
• Built-in stimulator in the recorder unit.
• Dual-channel biopotential amplifier plus two general-purpose channels.
• Intelligent inputs with automatic transducer gain adjustment.
• Firmware and software upgradeable free via the web.
• Sampling modes: continuous and snapshot; speeds from 1 kHz to 100 kHz.
• USB interface to PC with aggregate sampling up to 100 kHz continuous.
• Electronic design meets or exceeds UL safety standards for laboratory use.

Technical specifications

• Commercial designation: POPULAR IX-214 (recorder unit).
• Model: IX-214.
• Enclosure: extruded aluminum, designed for classroom use.
• Channels: 4 (dual biopotential + 2 general-purpose).
• Supported signals: EEG, EMG (EOG), ECG, pressure, temperature, force, voltage outputs from lab instruments.
• Built-in stimulator; optional high-voltage stimulus isolator.
• Interface: USB to PC; aggregate sampling up to 100 kHz continuous.
• Sampling modes: continuous and snapshot, 1–100 kHz ranges.
• Warranty: three-year unconditional hardware warranty.
• Software/Firmware: upgradeable via internet (free automatic upgrades).
• Minimum PC requirements: Pentium II class, >=64 MB RAM, >=10 MB free disk.
• Use cases: combined human and small-animal physiology teaching; supports dozens of experiments when used with teaching kits.
