Speed controller D30/5/4Q-E1

medical

Digital speed control - operates as «closed loop» speed controller Maximum speed 60,000 rpm (motor with 2 poles) Set value input through external analogue voltage Set value input through external PWM 200 Hz SCI protocol available Direction of rotation preset by a digital signal The output stage can be enabled or disabled Motor speed monitoring via «FG» output Status indication via «Ready» output Motor blocked protection (current limit for blocked motor) Protection: over-voltage, under-voltage, motor block, short-circuit The built-in shunt regulator is designed to limit the supply voltage of the controller Compact aluminum housing (110 x 80 x 34 mm) compliant
