Portable ultrasound system Intelect® Legend 2

for musculoskeletal ultrasound imagingB/Wbuilt-in console

Product overview
The Intelect® Legend 2 2CH Combo is a two-channel combination electrotherapy and ultrasound system designed for clinical physical medicine applications. The unit supports portable battery operation and can be used with an optional magnetic cart for flexible clinic placement. Chattanooga’s VMS waveform and preset protocols help deliver efficient muscle contractions and reduce treatment setup time to improve workflow.

Key features

• 2&Go Treatments Save up to 12 preset or custom protocols directly on the home screen to start treatments within two button presses.
• VMS Waveform Proprietary VMS waveform provides stronger, more efficient muscle contractions with reduced neural fatigue while maintaining patient comfort.
• SPS Menu Select an indication to configure a treatment within three button presses rather than setting every parameter manually.
• Magnetic Cart Optional cart with magnetic attachment enables tool-free installation and easy device relocation within the clinic.
• Improved battery life Integrated battery support for extended portable use without excess cabling.
• 12 Electrotherapy Waveforms Includes VMS, VMS Burst, Interferential, Premodulated, Asymmetric Biphasic, Symmetric Biphasic, High Volt, Microcurrent, Russian, HAN, Direct Current, VMS FR.
• Compact industrial design App-like interface and familiar controls for intuitive clinical use.
• Dual-frequency ultrasound 1 MHz and 3.3 MHz selectable with 1 cm², 2 cm², 5 cm² and 10 cm² applicator options.
• Wide range of accessories available

Standard accessories

• 6×8 cm carbon electrodes (qty 4)
• Stim channel 1/2 leadwire kit
• Dura‑Stick® Plus 5 cm (2”) cloth, square
• USB drive Intelect Mobile 2
• Power cord
• Nylatex wrap (2 per pack)

Technical specifications
SKU: 81-5010-INT
Mains power: 100–240 VAC, 50/60 Hz, 1.0 A
Weight: 6.8 lb (3.1 kg)
Shipping weight: 10.8 lb (4.9 kg)
Dimensions: 14"L x 13.4"W x 5.9"H (35.5 cm x 34 cm x 15 cm)
Electrical safety class: Class 1, Electrotherapy Type B, Ultrasound Type B
Safety tests and standards: IEC 60601-1; ISO 10993-1; IEC 60601-2-5; IEC 60601-1-2; IEC 60601-2-10; IEC 60601-1-6; IEC 62366-1; IEC 62304; IEC 62133; ISO 14971
