Automatic system positioning to take 3 individual overlapping images and combine them into one seamless study. Procedure is performed with constant focus, rotating x-ray tube. Both horizontal and vertical stitching procedures are supported. A stitching stand is available to assist frail patients.
KEY FEATURES
auto-stitching functions (with fixed focus position) for wall stand with optional stitching stand
2-way vertical auto-tracking between tube assembly and wall stand receptor (dynamic master/slave function)
2-way vertical auto-tracking between tube assembly and table receptor (dynamic master/slave function)
1-way auto-centering between tube assembly and table receptor (tube: master, receptor: slave)
motorized vertical movement of X-ray tube assembly (with manual override)
manual horizontal movement of tube stand
manual transverse movement of tube stand
motorized tube rotation on the horizontal axis (with manual override)
manual tube rotation on the vertical axis
motorized vertical movement of wall stand (with manual override)
motorized elevating radiographic table
motorized Phoenix 2 table receptor auto-centering (with manual override)
longitudinal and vertical SID measurement
optional manual or motorized receptor tilting for wall stand
