Instrument sterilization basket DJ-46 series
perforatedstainless steelwire

Instrument sterilization basket - DJ-46 series - DAUD JEE MFG. CO - perforated / stainless steel / wire
Instrument sterilization basket - DJ-46 series - DAUD JEE MFG. CO - perforated / stainless steel / wire
Add to favorites
Compare this product
Go to the DAUD JEE MFG. CO website for more information

Characteristics

Applications
for instruments
Other characteristics
wire, perforated, stainless steel

Description

Product overview
  • Side-perforated sterilization basket designed for safe washing and sterilization of surgical and dental instruments.
  • Manufactured in stainless steel AISI-304 with electro-polished finish.


Key features
  • Side wall perforation protects sharp instrument edges and tips from damage (perforation hole size: 2.0 mm).
  • Wire mesh base (square opening 6.0 mm, wire diameter 1.2 mm) provides secure support and drainage.
  • Top and bottom frame diameter: 5.0 mm for structural integrity.
  • Burr-free design and smooth round edges to reduce instrument damage and risk of operator injury.
  • Inner mounted drop handles for compact handling and compatibility with trays and racks.
  • Compatible with automatic washing and sterilization cycles.
  • Separate lids available: single frame, double frame and detention frame. Stacking frame available on request.


Available options
  • DJ-4610 - 240x120x30
  • DJ-4611 - 240x120x50
  • DJ-4612 - 240x120x60
  • DJ-4608 - 240x120x70
  • DJ-4609 - 240x120x100
  • DJ-4607 - 240x250x30
  • DJ-4613 - 240x250x50
  • DJ-4615 - 240x250x60
  • DJ-4616 - 240x250x70
  • DJ-4617 - 240x250x100
  • DJ-4656 - 405x250x30
  • DJ-4657 - 405X250X50
  • DJ-4658 - 405X250X60
  • DJ-4659 - 405X250X70
  • DJ-4660 - 405X250X100
  • DJ-4606 - 480x250x30
  • DJ-4618 - 480x250x50
  • DJ-4619 - 480x250x60
  • DJ-4620 - 480x250x70
  • DJ-4621 - 480x250x100
  • DJ-4661 - 540x250x30
  • DJ-4662 - 540X250X50
  • DJ-4663 - 540X250X60
  • DJ-4664 - 540X250X70
  • DJ-4665 - 540X250X100
  • DJ-4622 - 300x300x50
  • DJ-4623 - 300x300x60
  • DJ-4624 - 470x400x60
  • DJ-4625 - 480x480x50
  • DJ-4626 - 480x480x60
  • DJ-4628 - 500x300x50
  • DJ-4632 - 550x430x50
  • DJ-4634 - 600x300x60


Technical specifications
  • Product Code: DJ-4610 (example model; see Available options for full list)
  • Material: Stainless steel AISI-304
  • Surface finish: Electro-polished
  • Perforation hole size (side wall): 2.0 mm
  • Top and bottom frame diameter: 5.0 mm
  • Wire mesh base opening (square): 6.0 mm
  • Wire diameter (mesh base): 1.2 mm
  • Design: Burr-free, smooth round edges
  • Handles: Inner mounted drop handles
  • Lid options: Single frame, double frame, detention frame (separate lids available)
  • Compatibility: Suitable for automatic washing and sterilization processes
  • Optional accessories: Stacking frame available on request
Go to the DAUD JEE MFG. CO website for more information
