Crank-propelled recumbent bicycle motion cycle 900

pediatricadultheight-adjustable

Product description The new motion cycle 900 has been completely reworked biomechanically to meet the requirements for an optimal, individual training position. The refined display is complemented by multiple construction optimizations such as a wider, low step-through (approx. 36–41 cm) and a low axle position for easier mounting and dismounting. Children can use the motion cycle 900 from a body height of approx. 125–135 cm. The seat post offers a very wide adjustment range (user heights up to approx. 205 cm). The Q‑factor is only 18 cm; horizontal saddle adjustment is possible. An optional adjustable handlebar version is available that pivots horizontally and vertically to allow upright or triathlon positions; the mechanism enables low‑play fixation with little force.

Further descriptions / details

• Extensive adjustment options for seat and handlebar position (large adjustment range).
• Optional length‑adjustable stainless steel crank, tool‑free adjustable, scaled in 1‑cm increments (radius 55 mm to 175 mm).
• Optional motion easy move system for easy moving and fixing of the device, particularly suitable for space‑constrained settings or frequent transport to the patient.
• Accessibility: optimized access points in several places on the device for safe, low‑barrier mounting and dismounting.

Functions

• Vivid, full‑colour presentation
• Durable, clear touch display
• Quick Start, time training, heart‑rate training
• Interference‑free Polar® hybrid heart‑rate display with automatic pairing
• Low, wide step‑through
• Vertically and horizontally adjustable saddle

Options

• performance package (Qi charging option, max. 950 Watt, with optional power supply min. 7 Watt)
• connect package for system integration (RFID, NFC, Bluetooth® Low Energy, barcodes)
• programme package (10 training programmes, test profiles, motion balance system, serious games, programme memory)
• “all‑in‑package”: performance + connect + programme package
• boosted cycle – increased user weight limit to 200 kg
• Length‑adjustable cranks, tool‑free adjustable
• motion easy move rolling lift system
• Handlebar adjustment (optional)
• Housing in anthracite colour option
• Certification according to (EU) 2017/745, Class IIa (option / equipment feature)

Notes from application examples

• Enables training for children and adults (examples in the material show persons from approx. 1.25 m body height).
• Suitable for settings with frequent relocation of the device (motion easy move).

Characteristics / technical specifications (summary)

• 7‑inch capacitive touch display
• Polar® auto connection (5 kHz & Bluetooth® Low Energy), backward compatible; optional: ANT+
• Mono belt drive, self‑adjusting
• Calibrated and re‑calibratable, quiet HBS brake
• Side‑dependent power display
• Possible operation without mains power
• Relevant standards: DIN EN ISO 20957‑1 S‑A‑I, DIN EN ISO 20957‑5 S‑A‑I, DIN EN 60601‑1‑2
• Medical device certification according to (EU) 2017/745, Class IIa (indicates medical equipment features)
• Medical power range: 15 – 500 Watt, speed‑independent
• Fitness power range: 25 – 500 Watt, speed‑independent
• Cadence range: 15 – 140 rpm
• Max. user weight: 150 kg (option boosted cycle to 200 kg)
• Dimensions: approx. 119 x 65 x 145 cm
• Weight: approx. 58 kg
• Step‑through: approx. 36–41 cm
• Saddle adjustment range: user heights up to approx. 205 cm
• Q‑Factor: approx. 18 cm
• Crank adjustable: radius 55 mm to 175 mm, scaled in 1‑cm increments (stainless steel)
