Pendant lighting EVO Cone

for dental facilitiesLED

Presentation
The EVO Cone combines decorative design, high-quality light output and acoustic comfort. Circular conical LED acoustic pendant delivering vertical architectural presence. The felt acoustic panel improves the sound environment with acoustic performance reaching up to NRC 0.7 depending on configuration. CRI 90 and flicker-free operation for visual comfort in premium spaces.

Key features

• Vertical conical silhouette for a strong architectural statement.
• Felt acoustic panel: acoustic absorption up to NRC 0.7 (depending on configuration).
• High-end light output: CRI 90, efficacy 100–110 lm/W, LED type SMD2835.
• Flicker-free operation and power factor 0.90.
• Control options: ON/OFF, 0-10V dimming, DALI dimming.
• Suspended installation (installation quoted per project).
• 5-year luminaire warranty.

Recommended applications

• Reception areas
• Waiting rooms
• Offices
• Premium consulting rooms
• Clinics / medical centres
• Contemporary architectural projects

Specifications summary (excerpt)
Type: Circular LED acoustic pendant
Profile: Aluminium 6063 with lens and felt acoustic panel
Supply: AC100-277V / AC220-240V, 50-60Hz
LED: SMD2835
Drivers: BOKE / LIFUD
Correlated color temperatures: 3000K / 4000K / 6000K
Luminous efficacy: 100–110 lm/W
CRI: 90Ra
Power factor: 0.90
Operation: Flicker-free
Beam angle: 120°
Control modes: ON/OFF, 0-10V dimming, DALI dimming
Mounting: Suspended — installation quoted per project
Fixed height: 620 mm
Available diameters: Ø560 / Ø760 / Ø960 / Ø1260 / Ø1560 mm
Powers: 24W–48W
Luminous flux: 2000 lm–5000 lm
Acoustic colours: Red, green, blue, grey, brown, pink, beige, black, white, orange + 48+ additional colours available
Acoustic performance: NRC up to 0.7 (dependent on configuration, supplier data)
IP rating: IP20
Warranty: 5 years
Indicative price: From €3,000 excl. VAT, depending on configuration
Delivery: Europe, quoted per project

Technical characteristics / specifications

• Type: Circular LED acoustic pendant
• Profile: Aluminium 6063 with lens and felt acoustic panel
• Supply: AC100-277V / AC220-240V, 50-60Hz
• LED: SMD2835
• Drivers: BOKE / LIFUD
• Correlated color temperatures: 3000K / 4000K / 6000K
• Luminous efficacy: 100–110 lm/W
• CRI: 90Ra
• Power factor: 0.90
• Operation: Flicker-free
• Beam angle: 120°
• Control modes: ON/OFF, 0-10V dimming, DALI dimming
• Mounting: Suspended (installation quoted per project)
• Fixed height: 620 mm
• Available diameters: Ø560 / Ø760 / Ø960 / Ø1260 / Ø1560 mm
• Powers: 24W–48W
• Luminous flux: 2000 lm–5000 lm
• Acoustic colours: Over 48 colours (e.g. red, green, blue, grey, brown, pink, beige, black, white, orange)
• Acoustic performance: NRC up to 0.7 (depending on configuration)
• IP rating: IP20
• Warranty: 5 years
• Indicative price: From €3,000 excl. VAT
