Mortuary cooling unit YSSTG0109

A stainless-steel mortuary refrigerator engineered for clinical and funeral-mortuary use to store up to 4 bodies with precise temperature control and integrated alarm/data functions.

Product overview

• Forced cold-air circulation cabinet providing uniform cooling and stable temperature control for body storage and short-term freezing.
• Capacity: 4 bodies; robust stainless-steel interior and exterior for corrosion resistance and ease of cleaning.

Temperature control & monitoring

• Computer-controlled temperature system with 0.1°C display and adjustment precision; set range -16°C to 6°C.
• High-resolution calibration function (±10.0°C range with 0.1°C increments) and three-digit high-brightness display.
• Intelligent fan-controlled forced-air circulation to ensure uniform temperature distribution.

Recording, data & alarms

• Optional temperature recording/printing system with multiple internal sensors (typically four) and external indicators for upper/lower points.
• Power-off memory for permanent storage of temperature data and password-protected printing.
• Five-way alarm: dual audible (220V), dual visual (220V) and optional remote signal; alarms for high/low temperature, sensor failure, door open, power failure, low backup battery and low voltage.
• Optional RS-232 data interface and management software to display temperature curves, store and print records.

Safety & control

• Keyboard lock and password protection with separate operator and supervisor menus.
• Start-delay self-check and interval protection between stop and start to prevent compressor damage.
• Automatic recording of maximum and minimum temperatures; continued safe operation under sensor-fault or numerical-disturbance conditions.
• Built-in lithium accumulator to power display and alarms up to 72 hours after mains failure.

Refrigeration system

• Original Germany DANFOSS high-performance compressor.
• Imported Bi-Sonic dual fan for low-temperature/moisture environments and Germany EBM heat-exhaust fan.
• Fluoride-free refrigerant for environmental compliance.

Design & usability

• Stainless-steel interior/exterior shells for corrosion resistance and hygienic surfaces.
• Imported polyurethane foam insulation for thermal retention and efficiency.
• Durable gel-strip door gasket and roller-equipped body trays for easy handling; secure lock design to prevent accidental opening.
• Independent refrigeration circuits per chamber design (where applicable) and wide voltage support (187–242 V).

Optional items

• EPS emergency power supply (optional).
• DC24V–AC220V inverter and DC24V power supply option for DC operation continuity.

Technical specifications

• Model: YSSTG0109
• Capacity: 4 bodies
• Voltage/Frequency: 220 V / 50 Hz
• Input power: 2610 W
• Operating temperature in cabinet: 5 ~ -10°C (table indication)
• Adjustable set range: -16°C ~ 6°C
• Display & adjustment precision: 0.1°C
• Temperature sensors: typically 4 internal (+ 2 external indicators)
• Exterior size (W×D×H): 2300 × 2360 × 1785 mm
• Weight: 990 kg
• Compressor: Germany DANFOSS
• Fans: Bi-Sonic dual fan; Germany EBM heat-exhaust fan
• Refrigerant: fluoride-free (environmentally friendly)
• Power backup: built-in lithium accumulator (alarms/display up to 72 hours)
