RF body contouring unit Fisioline Radiant®

RF skin rejuvenation unittrolley-mounted

Product overview
Fisioline Radiant® is an innovative radiofrequency generator that administers energy via the passage of electrical current with monopolar, bipolar and tripolar effects, in capacitive or resistive modes. The device induces heat by electromagnetic waves to stimulate natural cellular processes in a non-invasive way, promoting collagen and elastin production and improving skin tone, texture and microcirculation.

Available versions

• Fisioline Radiant® 200: 200W – 350VA of power
• Fisioline Radiant® 300: 300W – 400VA of power
• Fisioline Radiant® 400: 400W – 450VA of power
• Fisioline Radiant® Mobile: portable version with 200W – 350VA of power and a practical carrying case

Indications

• Skin rejuvenation and skin refreshing: treats signs of ageing on face, neck and décolleté; stimulates collagen and elastin for an overall lift effect
• Skin toning and firming: counters sagging, causes contraction of the skin with visible plumping and lifting effects
• Cellulite, vasodilatation and drainage: vasodilating and draining effects to eliminate stagnant liquids, improve micro-circulation and reduce orange-peel effect and localized edema

The pluses

• Radiant Assistant: crash course of radiofrequency embedded in the technology
• Energy Power Bar: interactive system between operator and energy
• Long-lasting results
• Bipolar and resistive tripolar handpieces (including circular and sphere resistive bipolar handpieces)

Two modes of heat transmission

• Capacitive mode
• Resistive mode

Triple effectiveness and handpieces
Fisioline Radiant® features resistive bipolar (circular and sphere) and tripolar handpieces. Resistive bipolar handpieces do not require a reference electrode and allow precise definition of the treated area, enabling treatment of regions (e.g., head and neck) not easily treatable with monopolar methods. Tripolar resistive handpieces provide an alternative optimizing energy distribution for focused dosing and a pleasant warmth sensation.

Multifrequency and switching modality
Unique in its kind, the device offers up to 7 selectable frequencies (usable in both resistive and capacitive modes) that act at different tissue depths and allow maximum flexibility and personalized treatments.

• 7 frequencies selectable during treatment
• Automatic scanning / Switching modality: automatic bidirectional scanning of frequencies (from 448 kHz up to 1000 kHz or from 1000 kHz down to 448 kHz) enabling simultaneous or sequential use of all 7 frequencies for focused action on different tissue depths

Emission modes (continued and pulsed)
Fisioline Radiant® combines continuous and pulsed emission to control hyperthermia effects. Pulsed mode allows setting a DUTY-CYCLE adjustable from 10% up to 90% (customising erogation and pause times) — useful for acute musculoskeletal pathologies or athermic treatments (recent traumatic injuries).

Energy Power Bar
The device includes an electronic meter that continuously measures voltage/current and calculates tissue impedance (Ohm). The Energy Power Bar displays transferred energy across three sectors: HYPOTHERMIA (blue), NORMOTHERMIA (green, optimal transfer) and HYPERTHERMIA (red). The bar filling is inversely proportional to measured impedance and provides controlled, measured energy feedback during treatments.

Wizard, treatment protocols and user interface
Fisioline Radiant® features an intuitive colour touch-screen user interface with a Wizard (digital guide) that enables selection and control of operation functions and parameters. The operator can use preset treatment protocols or create and save personalized programs. The interface displays parameters on a large 7" touch-screen for remote reading and operator control.

Multimedia training
Preset therapeutic protocols are matched to illustrative video tutorials (accessible from the device console), showing operator movements and facilitating rapid use even by operators without prior radiofrequency experience.

Caractéristiques / spécifications techniques

• Commercial name: Fisioline Radiant®
• Product family: monopolar, bipolar and tripolar radiofrequency (capacitive and resistive)
• Models and rated power: 200 (200W – 350VA), 300 (300W – 400VA), 400 (400W – 450VA)
• Mobile version: portable with 200W – 350VA and carrying case
• Frequencies: up to 7 selectable frequencies; automatic scanning between 448 kHz and 1000 kHz
• Emission modes: continuous and pulsed; Duty-Cycle adjustable from 10% to 90%
• Handpieces: resistive bipolar (circular and sphere) and tripolar resistive; bipolar handpieces
• Energy monitoring: impedance measurement in Ohm and Energy Power Bar (three sectors: hypothermia / normothermia / hyperthermia)
• Display: 7" colour touch-screen
• Integrated features: Radiant Assistant (training), Wizard (protocols), multimedia video tutorials
