Veterinary surgery veterinary laser system Gbox plus

veterinary biostimulationdiodeGaAlAs

Overview
Gbox plus is a multifunctional veterinary laser therapy system with independently adjustable five-wavelength semiconductor output. It is designed to provide configurable treatment protocols for different lesions, tissue depths and clinical needs. Indications include pain relief, anti-inflammatory therapy, wound healing, tissue repair and rehabilitation, and selected surgical laser applications.

Core features

• Five independently adjustable wavelengths: 1064 nm, 980 nm, 915 nm, 810 nm, 635/650 nm (red light; system supports red-light targeting of superficial receptors).
• Supports continuous wave (CW) and super-pulse (ISP) operating modes.
• Allows creation and saving of individualized treatment protocols per patient.

Wavelengths and target tissues

• 650 nm (/635 nm) — superficial receptors: accelerates surface healing, enhances cell regeneration, reduces antibiotic use, shortens healing time and targets superficial receptors.
• 810 nm — mitochondria: increases ATP conversion, accelerates cellular metabolism, penetrates tissues and stimulates immune responses.
• 915 nm — hemoglobin: improves oxygen delivery to tissues, enhances analgesia and healing, and stimulates immune activity in deeper tissues.
• 980 nm — blood and water in tissues: improves circulation, relieves pain, reduces morbidity and accelerates recovery.
• 1064 nm — deep penetration: reaches deeper tissues with reduced water absorption to stimulate cellular activity at depth.

Output power and operating modes

• Example continuous output parameter: CW 42 W (page reference).
• Example super-pulse peak/mode: ISP 57 W (page reference).
• 650 nm red light single-channel output: up to ~2000 mW (page reference).
• ISP super-pulse uses variable-frequency pulsing to allow tissue cooling between pulses, reducing burn risk while stimulating deeper tissue, ATP production, collagen synthesis and circulation.

Applicators and spot sizes

• Open treatment head: 30 mm spot diameter.
• 30 mm spherical contact lens.
• 10 mm spherical contact lens.
• 5 mm TMJ guided applicator (for small-area treatments such as temporomandibular joint).
• 30 mm 360° rolling massage applicator (for large-area or rolling treatments).

Battery and portability

• Run time at full power: approximately 1 hour; typical operation up to ~4 hours; standby up to 7 days.
• Removable battery design for enhanced portability and on-site treatment flexibility.

Intelligent software and protocol management

• Smart system recommends treatment parameters based on condition, weight, BMI and skin type, with support for parameter customization to optimize outcomes.
• Enables creation, saving and recall of personalized treatment protocols to standardize clinical workflow.

Clinical indications

• Pain management and analgesia.
• Anti-inflammatory therapy and reduction of inflammatory response.
• Wound healing and tissue repair.
• Rehabilitation therapy and sports injury recovery.
• Surgical assistance (cutting, tissue repair and related laser applications).

Features / Technical specifications

• Product model: Gbox plus (trade name).
• Wavelengths: 1064 nm, 980 nm, 915 nm, 810 nm, 635/650 nm (red light).
• Example continuous mode parameter: CW 42 W.
• Example super-pulse mode parameter: ISP 57 W.
• 650 nm red light power: up to approx. 2000 mW (page reference).
• Applicators and spots: 30 mm open, 30 mm spherical contact, 10 mm spherical contact, 5 mm TMJ, 30 mm 360° rolling lens.
• Battery: full-power ~1 hour; typical operation ~4 hours; standby 7 days; removable battery.
• Software: intelligent parameter recommendations, supports personalized protocol creation and storage.
• Clinical uses: pain relief, anti-inflammation, circulation improvement, wound healing, targeted treatment of superficial and deep tissues and rehabilitation therapy.
• Manufacturer: 武汉翊晟科技有限公司 (manufacturer information appears on the page).
