1-bay surgical sink SURG 1 Inox

stainless steelknee-operated

Overview
The SURG 1 Inox is a 1-station stainless steel surgical basin designed for complete surgical washing of hands and forearms up to the elbows. Constructed from 304 stainless steel with a satin polished, bacteriostatic surface, the monobloc welded design eliminates joints and bacterial retention zones. Intended for surgeons, anesthetists, scrub nurses and personnel in operating rooms, sterile units and high-risk infection areas.

Electronic infrared sensor
The infrared electronic control allows completely hands-free water activation (mains or battery). The integrated infrared sensor ensures hygienic, safe operation compliant with strict hospital protocols. Advantages include:

• Hands-free infrared electronic control (mains or battery).
• Timed water flow to optimise water use and savings.
• Programmable automatic purge to prevent stagnation and bacterial growth.
• Settings accessible via an infrared remote on the front panel (no disassembly required).
• Monobloc stainless steel surgical basin: no joints or adhesives, eliminating bacterial retention zones.
• Wall-mounted tap to reduce contaminant deposits and simplify maintenance.
• Integrated backsplash and side panels to limit splashes on walls and floors.

Knee-operated control (hands-free)
The SURG 1 Inox with knee control allows water activation by pressing the knee for a robust, hygienic mechanical system. Advantages include:

• Timed knee control with integrated water saving.
• Monobloc stainless steel basin eliminating bacterial niches.
• Deep stainless steel basin for comfortable washing with reduced splashes.
• Wall-mounted tap for easier cleaning and fewer contact points.

Elbow control
The elbow control option provides hygienic and convenient water activation without hand contact, preserving sterility. Advantages include:

• Ergonomic elbow control ideal for operating environments.
• Monobloc smooth surface with no joints or adhesives.
• Deep, rounded basin to reduce splashing.
• Stainless steel backsplash and side panels for enhanced splash protection.

Foot control
The foot-controlled SURG 1 Inox provides hands-free activation via foot press. Advantages include:

• Temporized foot control: hygienic, economical and ergonomic activation.
• Monobloc stainless steel basin preventing bacterial retention.
• Deep basin for comfortable washing and splash reduction.
• Wall-mounted tap reducing contaminant deposits and facilitating cleaning.

Features and advantages (general)

• Monobloc stainless steel basin, welded without joints or seams.
• Compact 1-station format suitable for operating rooms and pre-surgical areas.
• Large deep basin designed for full arm surgical washing, reducing splashes.
• Multiple hygienic control options: infrared electronic, knee-operated, elbow control, foot control.
• Hands-free activation to preserve the aseptic chain.
• Integrated temporization to optimise water consumption.
• Programmable automatic purge system to prevent stagnation and bacterial growth.
• Wall-mounted faucet to minimise contact points and facilitate cleaning.
• Integrated stainless steel backsplash and side panels to protect walls and floors.
• Hygienic design with no flat surfaces for placing objects and no water stagnation areas.

Ergonomics and integration
The SURG 1 Inox is designed for easy integration into hospital technical spaces, including constrained areas. Its functional design allows accessory installation without hindering use and supports aseptic washing protocols.

Technical specifications

• Model: SURG 1 Inox
• Material: 304 Stainless Steel, satin polished; bacteriostatic surface
• Construction: Monobloc welded stainless steel, no joints or adhesives
• Intended use: Complete surgical washing of hands and forearms up to the elbows
• Dimensions (Length × Width × Depth): 700 × 725 × 520 mm
• Weight: 20 kg
• Control options: Infrared electronic (mains or battery), Knee-operated (timed), Elbow control, Foot control
• Timed water flow for water optimisation
• Programmable automatic purge system to prevent stagnation and bacterial growth
• Settings accessible via infrared remote on the front panel (electronic version)
• Wall-mounted tap (reduces contact and eases maintenance)
• Integrated backsplash and side panels to limit splashes
• Deep, rounded basin design to minimise splashes and increase user comfort
• Hygienic design: no flat surfaces for placing objects, no water stagnation zones
• Suitable environments: Operating rooms, sterile units, high-risk infection areas
