Endoscope cleaning brush JZ-B05 series

surfaceplastictwin-head

Intended use
Cleaning the endoscope insertion tube and external surfaces after clinical use. Single-use device intended to support hygiene and infection control.

Product features

• Double-ended (bilateral) brush-head design for efficient residue removal; suitable for various endoscopic forceps and channels, facilitating straightforward cleaning operations.
• Plastic protective cap on the brush tip to protect the channel during insertion.
• Cost-effective single-use solution for clinical settings.
• Distinctive double-head configuration: the handle end has longer bristles for vapor/wash brushing and the small head is designed for instrument channel cleaning; shape enables access through narrow channels and bends.

Models and specifications
Model Number Outer tube diameter (mm) Effective length (mm) Brush head diameter (mm) Brush head length (mm)
JZ-B0510-23 Φ1.7/2.1 2300 5 10/5
JZ-B0510-23-S Φ1.7/2.1 2300 5 10/5
JZ-B0510-23-Q Φ1.7/2.1 2300 5 10/5
JZ-B0510-23-SO Φ1.7/2.1 2300 5 10/5
JZ-B0505-23 Φ1.7/2.1 2300 5 10/5
JZ-B0505-23-S Φ1.7/2.1 2300 5 10/5

Technical specifications

• Brand: JZ Biotech
• Intended use: Cleaning of endoscope insertion tube and external surfaces after use; single-use hygiene device.
• Design: Double-ended brush head; longer bristles at handle end for vapor/wash brushing; small head for instrument channel cleaning; plastic protective cap on brush tip.
• Application: Clinical single-use; compatible with various endoscopic forceps and channels.
• Available series: JZ-B05 series (examples: JZ-B0510-23, JZ-B0510-23-S, JZ-B0510-23-Q, JZ-B0510-23-SO, JZ-B0505-23, JZ-B0505-23-S).
• Outer tube diameter: Φ1.7/2.1 mm
• Effective length: 2300 mm
• Brush head diameter: 5 mm
• Brush head length: 10/5 mm
