Digital refractometer ORL 94AL

for the food industrybenchtopwith automatic temperature correction

Overview
The KERN ORL 94AL is a desktop digital refractometer for refractive index and alcohol-related measurements. It features a large, easy-to-read display with integrated temperature readout, automatic temperature compensation (ATC), wide measuring range and high resolution. Maintenance-free design and quick calibration with distilled water.

Key features

• Desktop digital refractometer with large display and integrated temperature readout
• Automatic temperature compensation (ATC)
• Mean value measurement supported
• Quick calibration with commercially available distilled water
• Preinstalled scales for Brix and multiple alcohol-related units; scale selection by button

Practical application set

• Preinstalled alcohol industry scales enable measurements for beer, wine and related applications

Pre-installed scales

• Brix
• Refractive index
• Percent by mass
• Volume percentage
• Plato
• Original gravity (specific weight)
• Oechsle
• Oechsle France
• Volume percentage (Wine)
• KWM (Babo)

Software
The free OXR-BASIC software is available for logging and exporting measurement results (download area).

Scope of delivery

• Pipette
• Storage case
• USB cable
• Power adapter
• Screwdriver
• Operating instructions

Technical data (summary)
Type: Desktop refractometer
Display: Digital
Area of application: Alcohol
Measuring method: Total reflection
Measurement temperature: 0 °C – 40 °C
Automatic temperature compensation: Yes
Protection class: IP43
Dimensions (W×D×H): 180×100×55 mm
Brix range: 0 % – 94 % (readout 0.1 %)
Refractive index range: 1.3330 – 1.5290 nD (readout 0.0001 nD)
Oechsle range: 0 – 150 °Oe (readout 1 °Oe)
Oechsle France range: 0 – 230 °Oe (readout 1 °Oe)
KMW (Babo) range: 0 – 25 °KMW (readout 0.1 °KMW)
Original gravity: 1.000 – 1.130 (readout 0.001)
Volume percentage: 0 % – 80 % (readout 1 %); range I: 0 % – 22 % (readout 0.1 %)
Percent by mass: 0 % – 72 % (readout 1 %)
System requirements (software): Intel Core i3 / AMD Ryzen 5 or higher, 2.8 GHz
GTIN/EAN: 4045761489431

Specifications

• Model: ORL 94AL
• Mean value measurements supported
• Preinstalled alcohol-related scales
• OXR-BASIC software for data logging and export
