Thermostatic test chamber SDC-04

climatichumiditytemperature

Overview
Labotemp Sand Dust Test Chamber SDC-04 provides a controlled environment to evaluate product resistance to airborne sand and dust under simulated field conditions. The chamber offers a 1000 L stainless steel workspace, temperature range from ambient to +50°C, humidity below 30% RH, and programmable blowing and test durations up to 99 h 59 min. It is configured for IP5X and IP6X dust ingress testing per IEC 60529 and ISO 20653, making it suitable for electronics, automotive components, lighting, military equipment and industrial assemblies. A programmable color LCD touch-screen controller with Ethernet and USB connectivity and a 16 A dust-proof specimen power outlet support efficient test management.

Operation & Design Details
The SDC-04 uses vertical airflow circulation combined with a vibration-assisted hopper to maintain uniform dust suspension and prevent powder accumulation, ensuring repeatable test conditions. A Nichrome heater keeps circulating talcum powder dry for stable performance. The integrated vacuum system with pressure gauge, regulator and air filter accurately simulates dust ingress. Interior surfaces are corrosion-resistant SUS304 stainless steel; the exterior is A3 steel with protective coating. Multiple safety protections (over-temperature, over-current, earth leakage and phase-sequence protection), a 7-inch programmable touch-screen, built-in LED observation lighting, viewing window and electromagnetic door lock simplify operation and enhance safety.

Key Features

• Uniform dust exposure via vertical circulation and vibration-assisted hopper for repeatable tests.
• 1000 L workspace with programmable 7-inch color LCD touchscreen; Ethernet and USB connectivity.
• Industrial construction: SUS304 interior and A3 steel exterior with protective coating.
• Programmable blowing and flight/test durations up to 99 h 59 min for extended cycles.
• Integrated vacuum system with pressure gauge, air filter and regulator for controlled dust ingress.
• Nichrome heating system to maintain dry circulating dust during tests.
• 16 A dust-proof specimen power outlet to power devices under test.
• Viewing window with built-in LED observation lighting and electromagnetic door lock.
• Comprehensive protections: over-temperature, over-current, earth-leakage and phase-sequence protection.
• Designed to perform IP5X and IP6X dust ingress tests per IEC 60529 and ISO 20653.

Applications

• Electronics & Electrical Equipment Testing
  Evaluate dust ingress resistance of enclosures, devices and components.
• Automotive Component Testing
  Perform sand and dust tests on parts, connectors and assemblies used in dusty environments.
• Lighting Equipment Testing
  Assess dust protection of luminaires, fixtures and electrical housings.
• Industrial Equipment Testing
  Verify enclosure protection and durability of industrial machinery for dusty conditions.
• Military & Defense Equipment Testing
  Support environmental qualification where resistance to airborne dust is required.
• Product Enclosure & IP Testing
  Suitable for conducting IP5X and IP6X dust ingress tests according to IEC 60529 and ISO 20653.

Specifications (table representation)
Performance & Test — Internal Volume: 1000 L
Performance & Test — Temperature Range: Ambient to +50°C
Performance & Test — Humidity Range: <30% RH
Performance & Test — Normal Wire Diameter: 50 μm
Performance & Test — Nominal Gap Between Wires: 75 μm
Performance & Test — Flight Time: 0 ~ 99 h 59 min
Performance & Test — Blowing Time: 0 ~ 99 h 59 min
Performance & Test — Maximum Noise: 65 dBA
Safety & Electrical — Exterior Material: A3 steel plate with protective coating
Safety & Electrical — Interior Material: SUS304 stainless steel
Safety & Electrical — Power Supply: 220V 50/60 Hz
Safety & Electrical — Environmental Conditions: 5°C to +35°C, ≤85% RH
Construction & Control — Door: One door with one viewing window
Construction & Control — Viewing Window Size: 475 × 475 mm
Construction & Control — Heating Element: Nichrome heater
Construction & Control — Vacuum System: Pressure gauge, air filter, pressure regulator and connecting tube
Construction & Control — Specimen Power Outlet: Dust-proof socket, 16 A
Construction & Control — Door Lock: Electromagnetic lock
Construction & Control — Internal Dimensions (W × D × H): 1000 × 1000 × 1000 mm
Construction & Control — Overall Dimensions (W × D × H): 1330 × 1450 × 1960 mm
Construction & Control — Net Weight: 415kg
Construction & Control — Gross Weight: 559kg
Construction & Control — Package Size: 1590x1550x2250mm
