Epoxy medical assembly adhesive

for medical devicesglassbiocompatible

Two component, high performance epoxy system featuring biocompatibility for bonding, sealing, coating, encapsulating and impregnation Key Features Exceptionally low viscosity Very long open time at room temperature Passes USP Class VI and ISO 10993-5 requirements Capable of resisting repeated sterilization Master Bond EP62-1LPSPMed is an ultra low viscosity, two part epoxy that passes biocompatibility testing. It has a forgiving mix ratio of 100 to 25 by weight. Upon mixing, the viscosity is markedly low and the working life is impressively long, 12-24 hours at room temperature. There are many curing options for EP62-1LPSPMed. The basic cure starts at room temperature overnight, followed by 3 options involving heat. First is heating for 8-10 hours at 60-70°C. Other options include 60-90 minutes at 80-100°C or 30-60 minutes at 125°C. Post curing at 100-150°C for 3-4 hours will help optimize properties. (Please see the cure section for more details.) EP62-1LPSPMed blends an array of attractive physical strength properties and reliable electrical insulation values. It bonds well to a wide variety of substrates including metals, composites, glass and many plastics. It is cryogenically serviceable and has good heat resistance, with a temperature range extending from 4K to +400°F. EP62-1LPSPMed offers superior resistance to EtO, radiation, chemical sterilization media and autoclaving.It can be used for both reusable and disposable medical devices. In very thin sections, this system will transmit light, but in thicker ones, it is opaque. Also, its low viscosity makes it useful for smaller potting and encapsulating applications.
