Blood flow imager MOORLDI2-BI

laser Doppler

Overview
Single-point imaging scans a laser beam back and forth across the tissue, building a blood flow map. This enables a single scan of an adult torso and supports both large-area and small-area assessments.

Key features

• Non contact imaging
• Scan times from 40 seconds (up to 2 minutes for larger scans)
• Large assessment area up to 50cm x 50cm
• Long reach mobile stand
• Results available immediately
• Capable of scanning both large areas (e.g. full torso) and small areas (e.g. fingers)

moorLDI2-BI Burns Software Version 4.0 Features
Improved Scanning features

• Four standard language options built in: English, German, French and Chinese
• Compatibility with BurnCase 3D software — enables export and overlay of assessment images onto 3D frames (requires BurnCase 3D installed)
• Improved burn report layout for clearer comparison of burn image, video picture and greyscale image
• Improved function for saving burn images for presentations and documents
• Marking beam changed to attenuated low power for reduced optical hazard
• Updated scanning module navigation for easier setup and movement through scanning steps
• Burn Site ‘Lund and Browder’ style schematic implemented with multi-site input for large-area scans
• Simplified calendar-style date input and support for different date/time formats
• Three-image display mode (Flux, LD Photo and Colour Video) added to aid interpretation

Improved Review Module features

• Improved compatibility with research version of software
• ROI definitions improved so multiple ROIs of different types can be defined on each image
• Automatic ROI file saving when results for Statistics, Histogram or Profile windows are saved
• Flux overlay and grid features implemented
• Flexible zoom in/out features

Improved Database Management

• Multiple data files can be inserted into the database
• Images can be saved to a separate file with improved save functions for publications and presentations
• Data and database backup and restore functions implemented
• Straightforward database repair functions

General improvements

• Improved help sections for end users
• “Calibrate” button added to main menu; advanced calibration kit with new mounting arm for precise calibration block location
• Flexible data and database folder locations
• Display functions modified to improve speed on slower PCs
• Contrast/brightness adjustments and improved interface
• Automatic database backup at exit (if file modifications made)
• 32-bit and 64-bit Windows OS compatibility
• DICOM features implemented (available when DICOM version is ordered)

Technical specifications

• Model: moorLDI2-BI (software version referenced: Burns Software v4.0)
• Imaging mode: single point laser Doppler (non-contact)
• Maximum mapped area: up to 50 cm x 50 cm in a single scan
• Typical scan times: from ~40 seconds up to ~2 minutes depending on area (notes in product text)
• Able to perform both large-area (e.g. adult torso) and small-area (e.g. finger) scans
• Immediate availability of results after scan
• Long-reach mobile stand available for positioning
• Software: multi-language support (English, German, French, Chinese); three-image display mode; improved ROI and review tools; database backup/restore and repair
• Compatibility: BurnCase 3D export/overlay (requires third-party BurnCase 3D software); optional DICOM features when DICOM version ordered
• System requirements: Windows 32-bit and 64-bit compatibility
• Calibration: advanced calibration kit available (includes mounting arm and calibration block functions)
• Reporting: improved burn report layout and functions to save images for presentations and publications
