Dental laser HeliPen

dental biostimulationphysical biostimulationdental surgery

Overview
HeliPen is a wireless dental diode laser pen designed for clinical and office-based dental procedures. It integrates dual-wavelength configurations to support both photobiomodulation (PBM) therapy and precision soft‑tissue interventions in a compact, pen-style handheld device.

Key Benefits

• Dual-wavelength configuration enabling combined clinical pathways for therapy and precision soft-tissue work.
• Compact, pen-style, foot-pedal-free operation for easy integration into clinic workflows and portable use.
• Full-aluminum body to enhance heat dissipation and stabilize continuous operation.
• Extended battery system with three replaceable lithium batteries plus a charging dock for prolonged use and minimal downtime.

Two Exclusive Clinical Pathways
Pathway A: HeliPen Omni

• 980 nm + 650 nm simultaneous emission for deeper tissue support and recovery-focused applications.
• 980 nm optimized for soft-tissue handling and coagulation support.
• 650 nm dedicated to photobiomodulation (PBM) for comfort and recovery support.
• Up to 8 W (peak) at 980 nm for stronger energy delivery when required.
• Compact and adaptable to daily clinical workflows.

Pathway B: HeliPen Surg

• 450 nm + 650 nm dual-wavelength configuration for precision soft-tissue procedures.
• 450 nm blue light for precise cutting and delicate soft-tissue handling with reduced lateral thermal spread.
• 650 nm for adjunctive PBM support to enhance patient comfort and recovery.

Smarter Control & Operation

• Integrated secondary display shows key parameters and device status for fast, clear interaction.
• Real-time synchronization between the wireless handpiece and secondary display to maintain consistent settings.
• Dual emission controls: tap-to-start/tap-to-stop and press-and-hold to suit clinician preference and reduce finger fatigue.
• Built-in gravity sensor to auto-adjust display orientation for left- or right-handed use.
• Preset clinical protocols for common procedures to simplify setup and improve workflow efficiency.

Design & Performance

• Lightweight, pen-style design for portability and versatile clinical positioning.
• Full-aluminum construction to increase the thermal dissipation area and improve thermal efficiency.
• Extended operating time supported by three replaceable lithium batteries and a charging dock to minimize interruptions.

Accessory Ecosystem & Clinical Applications

• Precision fiber tips available in 200 μm, 300 μm, 400 μm and 600 μm to match treatment needs (endodontics, periodontics, etc.).
• Dedicated specialty attachments for tooth whitening, PBM therapy and focused TMJ relief.
• Clinical application areas include periodontics, endodontics, LLLT/photobiomodulation, oral surgery, pedodontics and aesthetic procedures.

Technical specifications

• Models: HeliPen Surg and HeliPen Omni.
• Wavelengths (HeliPen Surg): 450 nm and 650 nm.
• Wavelengths (HeliPen Omni): 980 nm and 650 nm.
• Power (HeliPen Surg): 3 W (peak) / 2 W (CW mode) at 450 nm; 500 mW at 650 nm.
• Power (HeliPen Omni): 8 W (peak) / 4 W (CW mode) at 980 nm; 500 mW at 650 nm.
• Model type: portable, handpiece (pen) form factor.
• Operation modes: Continuous Wave (CW) and pulse mode.
• Aiming beam: 650 nm for both models.
• Emission controls: tap-to-start/tap-to-stop and press-and-hold.
• Accessories: fiber tips 200/300/400/600 μm; specialty attachments for whitening, PBM and TMJ therapy.
