Medicine cabinet Neop®

for medical devicesfor fluidshospital

Short description
Neop® 600 x 400 single-column mobile cabinets are designed for organised storage of medicines, fluids and medical devices in clinical environments. The range prioritises ergonomics, hygiene and compact footprint to support nursing rooms and technical platforms in hospitals and clinics.

Variants / Options

• Height:
  • 160 cm
  • 180 cm
• Slides (intercalaires):
  • Tilted in upper position
  • Tilted in upper position — 40 mm pitch
• Bumpers:
  • No
  • Yes
• Colors:
  • Green apple
  • Magenta pink
  • Sky blue

Additional accessories

• 600 x 400 ISO trays
• Partitioning kit
• Standard handle
• Extension lateral shelf

Characteristics / Technical specifications

• Complete welded one-piece structure in electro-galvanized steel with epoxy anti-corrosion treatment
• Colour strip: 70 µm calendered PVC film with acrylic adhesive
• Slides: ABS (40 mm pitch)
• Closing system (optional): roller shutter
• Locking system: code lock (optional)
• 6 wheels Ø 125 mm (2 with brake + 2 swivel), double locking on wheel and swivel pin
• 6 non-marking round stop blocks in EVA
• Non-marking rubber tyre, polyamide cover on wheel hub
• Empty weight: 100 kg (H 160) / 110 kg (H 180)
• Dimensions:
  • H 160 with bumpers: L 1055 x D 780 x H 1695 mm
  • H 160 without bumpers: L 1026 x D 738 x H 1695 mm
  • H 180 with bumpers: L 1055 x D 780 x H 1855 mm
  • H 180 without bumpers: L 1026 x D 738 x H 1855 mm
• Cabinet marking available on request (e.g. department, floor or facility)
