CT scan test phantom PURE CTDI

torsoheadpediatric

Description
This CT phantom for medical imaging is designed to measure the Dose Index (DI) and related CTDI metrics. It comprises three PMMA cylinders representing a pediatric head, an adult head and a body. The pediatric head nests into the adult head, which in turn nests into the body for multi-configuration testing and compact storage.

Allows evaluation of:

• Dose Index (DI)
• CTDI100 (central)
• CTDI100 (peripheral)
• CTDI free air
• CTDIvol (weighted CTDIw)
• CTDIw (weighted CTDI100)

Specifications

• Material: PMMA (polymethyl methacrylate) cylinders
• Components: 3 cylinders representing pediatric head, adult head and body
• Pediatric head diameter: 100 mm
• Adult head diameter: 160 mm
• Body diameter: 320 mm
• Cylinder length: 140 mm (each)
• Detector accommodation: holes for 8 mm, 10 mm and 13 mm diameter radiation detectors
• PMMA plugs provided to close detector holes when not in use
• Alignment markers for repeatable positioning

Supplied with

• Detailed user manual
• Robust carrying case for transport and storage

Standards compliance

• IEC 61223-3-5
• IEC 61223-3-6
• IEC 60601-2-44

Technical specifications

• Purpose: measurement and verification of CT dose indices in pediatric and adult configurations
• Construction: three nested PMMA cylinders for flexible testing geometries
• Measurement positions: central and peripheral holes compatible with common ionization chambers and radiation detectors (8/10/13 mm)
• Length per cylinder: 140 mm
• Storage: nests together and supplied with protective case
• Included accessories: PMMA plugs, alignment markers, user manual
• Applicable standards: IEC 61223-3-5, IEC 61223-3-6, IEC 60601-2-44
