Spine surgery headrest 10-231

for operating tablespositioningstainless steel

The prone head support is a surgical head support designed for procedures where the patient is positioned face down, providing stability and secure positioning. It features adjustable angles and a locking mechanism for quick and reliable adjustments during surgery.

Key features

• Unique locking system that secures both pivots with a single lever for fast, secure adjustments
• Head plate compatible with various cushions and can be raised horizontally
• Can be used in combination with a non-slip mat to prevent cushion movement

Adjustment angles

• Adjustment angle downwards: 110°
• Adjustment angle upwards: 45°

Technical specifications

• Length: 495 mm
• Width: 260 mm
• Height: 35–170 mm
• Weight: 3.7 kg
• SWL (Safe Working Load): 15 kg
• Material: Stainless steel, Aluminum, Antistatic fabric, Foam, Slow recovery
