Manual stander K110

pediatricmobile

Overview
The Prone Mobile Stander is a mobile prone standing frame designed to enable standing mobility for wheelchair users and clients with limited independent standing. It supports progression from non-weight-bearing assistance to full weight-bearing standing and is intended for clinical and educational settings to promote bone density, circulation, postural alignment and motor skill development.

Benefits

• Promotes mobility: removable large side wheels permit self-propulsion in a standing posture.
• Facilitates participation: wheels can be removed to allow approach to tables or counters for activities and therapy tasks.
• Supports rehabilitation goals: regular use assists strengthening of motor patterns and progression toward independent standing.

Features

• Adjustable body support (length, width, height)
• Arm prompts for positioning
• Communication tray for devices or materials
• Fleecy strap and knee straps for soft, secure support
• Optional seat pad
• Removable large side wheels and casters for maneuverability
• Wheel locks for stability during stationary tasks
• Accessible deck and caregiver-friendly adjustments

Components & Common Accessories

• Arm prompt set
• Mounting bracket
• Large removable side wheels
• Conversion kit
• Hand loops
• Communication tray
• Sandals and wedges
• Additional seat pads

Sizes & Dimensions (summary table)
Item / K110 Mini / K130 Small / K150 Medium / K170 Large
User’s overall height / 25 – 32 / 30 – 40 / 37 – 52 / 48 – 65
Overall length (in) / 25 / 25 / 32 / 39
Overall width (in) / 25 / 25½ / 29 / 33½
Overall height (in) / 22½ – 28 / 23½ – 30 / 31 – 39 / 37½ – 49
Width without big wheels (in) / 19½ / 21 / 24 / 28½
Wheel diameter (in) / 20 / 20 / 27 / 35
Length of body support (in) / 14½ / 20½ / 25 / 32
Width of body support (in) / 7–10 / 7–10 / 9–12 / 10–14
Height of body support (in) / 16½ – 22 / 22 – 29 / 29 – 38 / 36 – 48
Seat pad / N/A / N/A / 6 x 7 / 8 x 11
Item weight (lb) / 28 / 30 / 40 / 65
Maximum working load (lb) / 50 / 50 / 120 / 175

Resources (documents & manuals)
Product manual, brochure and positioning checklist are available as downloadable resources providing detailed fitting instructions, adjustment guidance and positioning protocols for safe clinical use.

Technical specifications

• Product type: mobile prone stander (dynamic stander with wheels)
• Support range: from non-weight-bearing assistance to full weight-bearing support
• Primary adjustable supports: body support length/width/height, knee straps, fleecy strap, optional seat pads
• Mobility options: removable large side wheels for self-propulsion; casters for maneuvering; wheel locks for stability
• Accessories: arm prompts, communication tray, hand loops, sandals/wedges, additional seat pads, conversion kit, mounting bracket
• Materials & finish: designed for caregiver access with largely tool-free adjustments
• Manufacture origin: assembled in the manufacturer's U.S. facilities
