Urinary system model PLMNNJ005

kidneybladderurethra

Product overview
This urological training model reproduces the male urinary tract at 1:1 scale for endoscopic procedure practice. Manufactured from highly soft silica gel, it is designed for performance testing, functional demonstration and hands‑on training with cystoscopes, ureteroscopes, guidewires and catheters. The model provides realistic visual and tactile feedback to accelerate operator familiarization with endoscopic techniques.

Features

• Anatomy reconstructed from CT/MRI data, reproducing penis, urethra, bladder, ureter and kidneys at 1:1 to align dimensions with clinical reality.
• Made of food‑grade soft silica gel (test certificate available) to simulate tissue texture and visual appearance.
• Compatible with cystoscopes, ureteroscopes and related instruments for training in lithotripsy, catheterization, stent placement and similar urological procedures.
• Integrated pump housed in the model base with power cord; supports direct water injection and circulation to simulate intraoperative irrigation.

Specifications
PN: PLMNNJ005
Main material: Highly soft silica gel (hardness 18A–30A)
Product size (L×W×H): 47 cm × 40 cm × 18 cm (18.5 in × 15.7 in × 7.1 in)
Scale: 1:1 based on CT/MRI data
Lead time: 15 days
Origin: Shanghai, China

FAQ

• Q: Can the model be customized? A: Yes — three kidney types are available for customization.
• Q: Which anatomical parts are included? A: Penis, urethra, bladder, ureter and kidneys; suitable for ureteroscopic and cystoscopic instrument drills.
• Q: Is the pump included? A: Yes — the pump is integrated into the base and supplied with a power cord; it allows water injection and circulation.

Technical specifications

• PN: PLMNNJ005
• Main material: Highly soft silica gel; hardness 18A–30A
• Model dimensions (L×W×H): 47 cm × 40 cm × 18 cm
• Scale: 1:1 based on CT/MRI
• Components: penis, urethra, bladder, ureter, kidneys
• Pump: integrated in base, includes power cord, supports water injection and circulation
• Applications: training and functional demonstration for cystoscope, ureteroscope, guidewire/catheter operations; urological procedures such as lithotripsy, catheterization, stent implantation
• Lead time: 15 days
• Origin: Shanghai, China
