Key cabinet WAP-A02

for defibrillatorhospitalwith door

Overview
The alarmed AED aluminum cabinet accommodates most major AED models. Constructed from 1.5 mm aluminum, it is compact, lightweight and designed for outdoor use with waterproof protection.

Product Attributes

• Brand: WAP
• Model: WAP-A02
• Material: Aluminum (1.5 mm)
• Color: Red, Dark green, Custom colors; two-tone option Cool Gray 10C + Red
• Size: H35 × W30 × D13 cm (350 × 300 × 130 mm); customized sizes available
• Function: AED storage (wall-mounted)

Product Features

• Body: 1.5 mm aluminum for corrosion resistance and easy maintenance
• Two-tone finish available (Cool Gray 10C + Red)
• Door handle: knob with key (reference #MS748) replacing magnetic or recessed handles
• Mounting: rear standard mounting holes with screws and waterproof washers (improved from hoist holes)
• Front window: beveled PC window with anti-UV treatment
• Designed for outdoor installation; waterproof construction

About this item

• Alarmed protection: Built-in alarm and strobe alert by sight and sound when the door is opened; alarm level approximately 85–120 dBA. Low-battery chirp included.
• Secure storage: Rigid aluminum enclosure reduces risk of damage or theft; AED card holder can be fitted for quick device identification.
• Installation: Wall-mounted with three rear fixing points; verify fit against secondary reference dimension 380 × 350 × 185 mm if required.
• Applications: Suitable for public spaces, workplaces, hospitals, emergency vehicles and outdoor sites requiring weatherproof AED access.

Additional information
WAP is a manufacturer specializing in professional AED cabinets. All WAP cabinets include a 2-year warranty and prompt after-sales support.

Technical specifications

• Model: WAP-A02
• Material: Aluminum, thickness 1.5 mm
• Main size: H35 × W30 × D13 cm (350 × 300 × 130 mm)
• Secondary size reference on page: 380 × 350 × 185 mm (confirm with supplier for exact fit)
• Colors: Red, Dark green, Custom colors; two-tone option Cool Gray 10C + Red
• Door handle: Knob with key (ref. #MS748)
• Front window: PC beveled glass, anti-UV
• Back mounting: Standard mounting holes with screws and waterproof washers
• Alarm: Built-in alarm and strobe; sound level ~85–120 dBA; low-battery chirp
• Protection: Outdoor use, waterproof construction
• Function: AED storage, wall-mounted
• Warranty: 2 years
