Automatic dishwasher BPW4260J-K5
front-loadinglow-consumptionstainless steel

Automatic dishwasher - BPW4260J-K5 - SMEG Instruments - front-loading / low-consumption / stainless steel
Automatic dishwasher - BPW4260J-K5 - SMEG Instruments - front-loading / low-consumption / stainless steel
Automatic dishwasher - BPW4260J-K5 - SMEG Instruments - front-loading / low-consumption / stainless steel - image - 2
Automatic dishwasher - BPW4260J-K5 - SMEG Instruments - front-loading / low-consumption / stainless steel - image - 3
Add to favorites
Compare this product
Go to the SMEG Instruments website for more information

Characteristics

Operation
automatic
Configuration
front-loading
Other characteristics
low-consumption, stainless steel, eco-friendly

Description

Highlights
  • Automatic opening: the door can open via foot pedal or proximity recognition system for contactless operation.
  • Intuitive display: color touch display with dedicated programs and ECO cycles for reduced water and energy consumption.
  • Loading flexibility: maximum flexibility with different supports; can process up to 2 pans or 4 utensil holders simultaneously, plus basins, pitchers and other aids.
  • Complete traceability: USB port for recording operating data and PC connection for diagnostics, cycle customization and data analysis.
  • Innovative multi-zone washing: three hydraulic circuits with fixed and rotating nozzles for optimal water distribution and targeted disinfection.
  • ZERO STEAM system: eliminates residual steam at the end of disinfection to prevent steam release when opening the door, increasing operator safety.
  • Clostridium difficile program: dedicated and validated program for effective disinfection against Clostridium difficile.


Intended use
  • Health Care sector: care homes; inpatient wards.
  • Instrument solutions: Health Science.


Appearance
  • Color: Stainless steel.


Type
  • Pot and pan washer with automatic opening.
  • Family: Pot and pan washers.


Programs
  • Stored standard programs: utensil holder program, standard pan program, intensive pan program.
  • Stored ECO programs: utensil holder ECO, pan ECO, intensive pan ECO.
  • Factory optional programs: multifunction basket program, Clostridium program.
  • Program modification possible: Yes.
  • A0 adjustable: Yes, 60 - 6000.


Racks and supports
  • Support types: 1 pan and 2 utensil holders (R-1B2P); 2 pans (R-2B).


Electrical connection
  • Electrical connection: 400V 3N AC 50Hz.
  • Single-phase version available: Yes.
  • 60 Hz option: Yes, on request.
  • Plug: Cable with free terminals.


Plumbing connection
  • Hot water connection with aquastop: Yes.
  • Cold water connection with aquastop: Yes.


Manuals and certifications
  • Medical Device according to (EU) 2017/745 MDR (Annex IX) class IIa: Yes.


Interface
  • Cycle archiving: Yes.
  • Electronic control: Yes.
  • Remaining time display: Yes.
  • End-of-cycle indicator: Yes.
  • Cycle archive download: Yes, via USB stick; Optional via LAN port; Optional via RS232 port.
  • Traceability: min. last 300 executed programs.
  • Display: LCD.
  • USB port: Yes.


Construction
  • External casing material: AISI 304.
  • Wash chamber material: AISI 304; AISI 316 optional.


Equipment
  • Steam condenser: Yes.
  • Chemical dosing control: Standard for anti-scale.
  • Peristaltic pump for liquid detergent dosing: Optional.
  • Detergent level sensor: Standard.
  • Peristaltic pump for anti-scale dosing: Yes.
  • Water Stop: Yes.


Medical device regulation
  • DMS reference: Version 04 - 21/04/2026.


Technical specifications
  • Washing capacity: 4 utensil holders; 2 utensil holders + 1 pan; 2 pans (optional).
  • Door: 1, automatic opening.
  • Door opening/closing: Automatic, by pedal or sensor or display.
  • Emergency door opening system: Yes.
  • Top spray arm: Yes.
  • Spray arm rotation control: Yes.
  • HEPA filter: Optional.
  • Sound pressure level: <60 dBA.
  • Dimensions (mm): 1600 x 600 x 450.
