Bedpan washer-disinfector BPW1290J-K5

for the medical sectorfor healthcare facilitiesundercounter

Overview
Pan washer with automatic opening and manual tilt door. Medical device according to Regulation (EU) 2017/745 MDR (Annex IX) class IIa.

Main features
Type: Automatic-opening pan washer.
Door opening/closing: Manual, tilt.
Washing capacity: 4 holders; 2 holders + 1 pan; 2 pans (optional).

Intended use
Health care sector: Nursing homes; Inpatient ward.
Instruments solutions: Health Science.

Aesthetics
Color: Stainless steel.

Type and installation
Under-counter installation: Yes.
Family: Pan washers.

Technical characteristics
Washing capacity: 4 holders; 2 holders + 1 pan; 2 pans (optional).
Door: 1, swing steel door.
Door opening/closing: Manual, tilt.
Emergency opening system: Yes.
Top spray arm: Yes.
Spray arm rotation control: Yes.
HEPA filter: Optional.
Sound pressure level (dBA): <60 dBA.
Product dimensions (mm): 860x900x650.

Programs

• Stored standard programs: Parrot program, Normal pans program, Intensive pans program
• Stored Eco standard programs: Parrot ECO program, Pans ECO program, Pans intensive ECO program
• Factory optional programs: Multifunction basket program, Clostridium program
• Possibility to modify programs: Yes
• A0 adjustable: Yes, 60 - 6000

Baskets
Support types: 1 pan and 2 holders (R-1B2P); 2 pans (R-2B).

Electrical connection
Connection: 400V 3N AC 50Hz.
Single-phase version available: Yes.
60 Hz possibility: Yes, on request.
Plug: Cable with free ends.

Hydraulic connection
Hot water connection with aquastop: Yes.
Cold water connection with aquastop: Yes.

Manuals and certifications
Medical device according to Regulation (EU) 2017/745 MDR (Annex IX) class IIa: Yes.
DMS reference: Version 02 - 21/04/2026.

Interface
Cycle storage: Yes.
Electronic control: Yes.
Remaining time display: Yes.
End-of-cycle indicator: Yes.
Cycle archive download: Yes, via USB key.
Traceability: min. last 300 executed programs.
Display: LCD.
USB port: Yes.

Construction
External casing material: AISI 304.
Washing chamber material: AISI 304; AISI 316 optional.

Equipment
Steam condenser: Yes.
Chemical dosing control: Standard for descaler.
Peristaltic pump for liquid detergent dosing: Optional.
Detergent level sensor: Standard.
Peristaltic pump for descaler dosing: Yes.
Water Stop: Yes.

Characteristics / technical specifications

• Product model: Pan washer BPW1290J-K5
• Type: Automatic-opening pan washer
• Washing capacity: 4 holders; 2 holders + 1 pan; 2 pans (optional)
• Door: 1 swing steel door, manual tilt opening
• Dimensions (mm): 860 x 900 x 650
• Sound pressure level: <60 dBA
• Power supply: 400V 3N AC 50Hz (single-phase version available)
• Materials: External AISI 304; washing chamber AISI 304 (AISI 316 optional)
• Medical device compliance: MDR (EU) 2017/745 class IIa
• Interface and traceability: LCD display, cycle storage, USB download, traceability min. last 300 programs
