Drainage catheter SMD 519 R

vesicalballoonmale

Product Overview
The Sterimed Hematuria TURP Catheter SMD 519 is a three-way, 100% silicone catheter designed for post-TURP continuous irrigation and efficient clot evacuation. Enlarged irrigation channel, wide drainage eyes and a soft high-capacity balloon support secure placement and effective bladder management after prostate resection.

Clinical Need After TURP Surgery

• Maintain hemostasis and reduce bleeding-related complications
• Prevent clot retention and bladder obstruction
• Enable continuous irrigation while minimising patient discomfort

Key Features

• Three-way configuration — simultaneous irrigation, drainage and balloon inflation
• 100% silicone shaft — structural resistance to collapse under clot load
• Enlarged irrigation channel — rapid saline flow for effective clot removal
• Wide drainage eyes — allow passage of larger clot fragments
• Soft, large-volume balloon (50–100 cc) — uniform inflation for secure bladder fixation
• Radiopaque line — facilitates X-ray positioning

How It Works

• Irrigation channel delivers continuous saline to prevent and flush clots
• Drainage channel and wide eyes evacuate clot-laden fluid efficiently
• Balloon channel secures catheter position to maintain continuous irrigation

Indications / When to Use

• Post-TURP irrigation and drainage management
• Severe hematuria requiring continuous irrigation
• Urology patients at high risk of clot retention

Sizes

• 18–20 Fr — Balloon capacity 50–80 cc/mL
• 22–24 Fr — Balloon capacity 80–100 cc/mL

Packaging
Sterile, individually packed in peelable pouch. Box of 10; master cartons: 400 and 600 pieces.

Technical Specifications

• Material: 100% silicone (reinforced shaft)
• Catheter type: Three-way hematuria / TURP catheter (irrigation, drainage, balloon channels)
• Irrigation channel: Enlarged for rapid saline flow and clot removal
• Drainage eyes: Wide openings to allow passage of larger clots
• Balloon: Soft, large-volume (50–100 cc depending on size)
• Radiopaque line for X-ray positioning
• Available sizes: 18–20 Fr and 22–24 Fr
• Packaging unit: Sterile, peelable pouch; box count: 10; master carton counts: 400, 600
• Example gross weights & carton dimensions: Gross 22.0 kg (600 pcs, 18 Fr); Gross 14.5 kg (400 pcs, 18 Fr); Carton sizes 555 x 503 x 555 mm (600 pcs), 550 x 330 x 535 mm (400 pcs)
• Product Codes: India: SMD 519 R; Exports: SMD 519
