Body tray refrigerated mortuary cabinet TOMU 6040
3-bodyside-loadingon casters

Body tray refrigerated mortuary cabinet - TOMU 6040 - Tiscomed - 3-body / side-loading / on casters
Body tray refrigerated mortuary cabinet - TOMU 6040 - Tiscomed - 3-body / side-loading / on casters
Add to favorites
Compare this product
Go to the Tiscomed website for more information

Characteristics

Applications
for body trays
Number of bodies
3-body
Loading
side-loading
Other characteristics
with door, for temporary storage, refrigerated, on casters, mobile

Description

Overview
  • Triple side-loading morgue unit for temporary storage of human remains
  • Constructed in 304 grade stainless steel for interior surfaces
  • Designed for use in sterile environments and available in different designs and dimensions
  • Provides a controlled cold environment to preserve body integrity until burial or transfer


Operation and handling
  • Front doors with lock system and internal release mechanism
  • Interior lighting automatically activates when a door is opened
  • Funeral trays in 1.2 mm 304 stainless steel with rail and pulley system for easy loading and unloading
  • Mobility via four lockable 125 mm wheels for positioning and cleaning


Technical specifications
  • Model: TOMU 6040
  • Construction material: 304 grade stainless steel (stainless steel sheets)
  • Tray material/thickness: 1.2 mm 304 grade stainless steel
  • Insulation: polyurethane density 38–42 kg/m³
  • Temperature control: digital indicator and control; standard 0 to +5 °C; optional -5 to +10 °C
  • Refrigerant: R290 gas (conforming to European directives)
  • Defrost: fully automatic
  • Cooling: fan-controlled internal cooler; condensate drain hose; stated cooling capacity 1400 kcal
  • Doors: front doors with lock and internal release; side-loading configuration (two or three doors depending on design)
  • Loading: side loading; triple configuration dimensions: 2500 + 500 mm motor x 1000 x 2200 H mm (side engine)
