Laboratory clean bench VALUE LINE

for research laboratoriesbenchtopon casters

Product overview
TopAir Value line horizontal laminar flow clean benches provide a controlled Class 100 / ISO 5 work environment for contamination-sensitive processes. Built on a metal epoxy-coated frame with a 304 stainless steel work surface, these benches draw ambient air through a HEPA H14 filter and deliver unidirectional, downward airflow over the workspace. Units are factory-tested to USA Federal Standard 209E / ISO 14644-1 and CE requirements.

Structure

• Metal cabinet with epoxy-baked finish
• Work surface: stainless steel 304
• Side windows: tempered glass
• Front sliding sash with counterweight

Red Light Alert
On air velocity failure the internal red indicator illuminates and the system performs automatic shutdown. The visual alarm enables remote fault detection and aids visibility for users including the hearing-impaired.

Features

• Microprocessor control with 7” color touchscreen
• Fan control with 10 speed settings
• Airflow display and alarm; filter replacement alarm
• High-efficiency low-noise EC fan
• Germicidal waterproof UV system (254 nm) with safety interlock
• 800 lux LED illumination
• Two universal electrical outlets
• Metal stand with casters for mobility
• Multi-language interface with metric/Imperial units
• Certifications: USA Federal Standard 209E / ISO 14644-1 / CE
• Optional Integrated Particle Monitoring System (IPMS)

Models / Table
Spec / Model | HC-H090 | HC-H120 | HC-H150 | HC-H180
Outer Dimensions WxDxH | 35.4 x 36.6 x 47.2” / 900 x 930 x 1220 mm | 47.2 x 36.6 x 47.2” / 1200 x 930 x 1220 mm | 59 x 36.6 x 47.2” / 1500 x 930 x 1220 mm | 70.8 x 36.6 x 47.2” / 1800 x 930 x 1220 mm
Workspace (W x D x H) | 30.3 x 24.4 x 23.6” / 770 x 620 x 600 mm | 42.1 x 24.4 x 23.6” / 1070 x 620 x 600 mm | 53.9 x 24.4 x 23.6” / 1370 x 620 x 600 mm | 65.7 x 24.4 x 23.6” / 1670 x 620 x 600 mm
Test Standard | USA Federal Standard 209E / ISO-14644-1 / CE
Air Velocity m/s | 0.33 m/s (66 fpm)
Cleanliness in Workstation | Class-100 (FS 209E) / ISO-5
Hood Material | Metal with epoxy-coated paint
Worktop Material | Stainless steel 304
Noise Level (by model) | <52 dB (HC-H090), <54 dB (HC-H120), <56 dB (HC-H150), <56 dB (HC-H180)
Power Supply | 110 / 220 V, 50/60 Hz, single phase
Illumination | 800 LUX LED lighting
Filters | HEPA H14, 99.9995% @ 0.3 μm (Optional ULTRA filter)

Technical specifications

• Cleanliness level: Class 100 / ISO 5 (tested to USA Federal Standard 209E / ISO 14644-1 / CE)
• Air velocity: 0.33 m/s (66 fpm)
• Worktop: stainless steel 304
• Cabinet: metal with epoxy-baked paint
• Illumination: 800 LUX LED
• Noise level (measured 20 cm from worktop, 1.2 m above floor): <52–56 dB depending on model
• Power: 110 / 220 V, 50/60 Hz, single phase
• HEPA filter: H14 (99.9995% @ 0.3 μm); ULTRA optional
• Control: microprocessor with 7” color touchscreen; fan control 10 speeds; multi-language display (metric/Imperial)
• Safety/alarms: airflow display and alarm; filter replacement alarm; red light alert and automatic shutdown on air velocity failure
• Optional: Integrated Particle Monitoring System (IPMS)
• Available models: HC-H090, HC-H120, HC-H150, HC-H180
