Indoor transfer chair YK-TC-003

electricliftwith armrests

Product overview
The YK-TC-003 transfer chair is an electric patient transfer and lifting chair designed for clinical environments. It provides a lifting range of 0 - 2100 mm and supports up to 230 kg. Width adjustment and compact base dimensions facilitate patient transfers and passage through doors.

Key features

• Material: Alloy carbon steel
• Load capacity: 230 kg
• Lifting range: 0 - 2100 mm
• Motor: 24 V / 8000 N
• Battery: 2 sets, medical lead-acid batteries
• Power cord length: Standard 3 m (customizable)
• Minimum width (before adjustment): 630 mm
• Expanded width (after adjustment): 950 mm
• Support height: 105 mm
• Base length: 1050 mm
• Push handle height: 1050 mm
• Armrest width: 800 mm
• Armrest length: 800 mm
• Auxiliary long armrest clearance: 850 mm
• Package size: 1100 × 670 × 330 mm

Technical specifications

• Model: YK-TC-003
• Material: Alloy carbon steel
• Rated load: 230 kg
• Lifting mechanism: Electric 24 V / 8000 N
• Lifting range: 0 - 2100 mm
• Widths: 630 mm (min) – 950 mm (expanded)
• Dimensions (base length): 1050 mm; support height: 105 mm
• Armrests: 800 × 800 mm; auxiliary clearance: 850 mm
• Power: 2 battery sets (medical lead-acid); cord standard 3 m
• Packing dimensions: 1100 × 670 × 330 mm

Applications

• Hospital wards and operating departments
• Rehabilitation and physiotherapy centers
• Nursing homes and long-term care facilities
• Ambulatory care and patient transport

Ordering & options
Standard supply includes the YK-TC-003 unit with two battery sets and standard 3 m power cord. Customization options: power cord length, additional battery configurations and accessories. Contact the supplier for compliance documentation, spare parts and transport packaging requirements.
