Research and development biosignal acquisition system PM-FCP8

for teachingfor research4-channel

Product overview
The PM-FCP8 physiological data acquisition system acquires, analyses and stores multi-site blood pressure and blood flow signals, generates corresponding waveforms and displays clear visual results for hemodynamic assessment in research and training environments.

Key details

• Model: PM-FCP8
• Payment: T/T
• Shipping time: 7 days
• Lead time: 7-15 days
• Shipping methods: FedEx, DHL, EMS, UPS, TNT

Dimensional drawing
Dimensional drawing available for PM-FCP8. Note: flow monitoring requires a dedicated flowmeter and customized configuration when needed.

Product features

• Modular integrated design tailored for hemodynamic analysis
• Synchronous acquisition, analysis and processing of blood pressure and blood flow signals
• Available configurations: 4-channel and 8-channel to support multi-point data collection

Product application
Designed for acquisition, waveform plotting and visualization of blood pressure and blood flow data on vascular models and test rigs. Suitable for hemodynamic research, device testing and educational simulations.

Equipment specifications
Item: Physiological data acquisition system
Model: PM-FCP8
Equipment weight: 3.3 kg
Equipment dimensions: 320 × 196 × 140 mm
Operating power (continuous): 100 W
Input voltage: AC 220 V, 50/60 Hz
Measurement accuracy: Blood pressure ±0.5%; Blood flow ±2%

Technical specifications

• Model: PM-FCP8
• Channels: 8-channel (option: 4-channel)
• Weight: 3.3 kg
• Dimensions: 320 × 196 × 140 mm
• Operating power (continuous): 100 W
• Input voltage: AC 220 V, 50/60 Hz
• Measurement accuracy: Blood pressure ±0.5%; Blood flow ±2%
