Real-time DNA amplification system Delphi Smart Quant

for qPCRgradientfluorescence

Product Description
The Delphi Smart Quant System FMR-5S is a real-time qPCR instrument optimized for research workflows. It integrates a 12.1" HD touchscreen, rapid thermal cycling, LED-based optics and flexible temperature-control modes to support high-throughput experiments and diverse analysis methods while remaining automation-ready.

Main Features

• Display: 12.1" HD touchscreen for intuitive setup and monitoring.
• Gradient optimization: 12-column temperature gradients to optimize conditions in a single run.
• Speed: Thermal ramp rates up to 8°C/s and 5-second full-plate fluorescence detection.
• Optics & stability: LED-based maintenance-free optics, long lifespan, auto-tray and multi-instrument control for automated labs.
• Sensitivity: Low background signals enabling detection of low-abundance targets.

Key Software Functions

• Flexible PCR and fluorescence parameter configuration.
• Easy thermal cycling program and sample metadata editing via touchscreen.
• Real-time monitoring of amplification curves and instrument status.
• Comprehensive analysis modes: absolute/relative quantification, genotyping, positive/negative calls, melt curve analysis, protein thermal shift assays, HRM, MMCA.
• Data export in multiple formats, direct printing support, remote firmware upgrades, built-in fault protection and alarms.

Product Options / Packaging

• Available region/configuration options: RUO-EN, RUO-EU, RUO-US.
• Catalog / Model number: FMR-5S.

Additional Product Notes

• Selectable temperature-control modes: module-based (block temperature) or tube-based (reaction liquid temperature) monitoring.
• A mouse is included in the packaging.
• Intended for Research Use Only (Not for use in diagnostic procedures).

Frequently Purchased Together

• VAMNE Magnetic Cell/Tissue Total RNA Kit (Prepackaged) — RMA330
• FastPure Cell/Tissue Total RNA Isolation Kit V2 — RC112
• FastPure Universal Plant Total RNA Isolation Kit — RC411
• HiScript IV All-in-One Ultra RT SuperMix for qPCR — R433
• HiScript IV RT SuperMix for qPCR (+gDNA wiper) — R423
• HiScript IV 1st Strand cDNA Synthesis Kit (+gDNA wiper) — R412
• SupRealQ Ultra Hunter SYBR qPCR Master Mix (U+) — Q713
• Taq Pro Universal SYBR qPCR Master Mix — Q712

Technical specifications

• Model / Catalog No.: FMR-5S
• Display: 12.1" HD touchscreen
• Throughput: full 96-well plate detection; 5-second full-plate detection capability
• Thermal ramp rate: up to 8°C/s
• Gradient capability: 12-column temperature gradients
• Optics: LED-based, maintenance-free, long lifespan
• Temperature control modes: module-based or tube-based (user-selectable)
• Automation-ready: auto-tray and multi-instrument control
• Software analysis modes: absolute/relative quantification, genotyping, positive/negative calls, melt curve analysis, protein thermal shift assays, HRM, MMCA
• Data handling: multi-format export, direct printing support, remote firmware upgrades, built-in fault protection and alarm
• Intended use: For Research Use Only (RUO)
