General purpose cabinet unit Eolis®

for medical instrumentsmodularon casters

Modular cabinet Eolis® depth 400 mm, double-drawer configuration, designed for storage and handling of ISO 600×400 accessories. Intended for industrial and medical environments; features modular internal rails, welded monobloc epoxy-coated steel body and swivel casters for mobility.

Main features

• Modular design with internal ABS rails enabling installation of ISO 600×400 accessories (drawers, bins).
• Open front with enclosure on 5 sides; closure by contiguous drawers (central locking optional).
• Welded monobloc body in epoxy-coated steel, available in 8 colour finishes.
• Standard equipment: manoeuvre handle on the left side.
• Mobility via Ø 125 mm swivel casters, 2 with brake; polyamide fork, grey non-marking rubber tread, stainless steel ball bearings; wheels fitted with wire guards.

Capacity options

• 2 × 22 modules
• 2 × 18 modules
• 2 × 14 modules

Technical specifications

• Compatible accessory format: ISO 600 × 400
• Closure type: contiguous drawers (central locking optional)
• Structure: welded monobloc body in epoxy-coated steel
• Finish: available in 8 colour options
• Handle: 1 manoeuvre handle (left side) supplied as standard
• Wheels: Ø 125 mm, 2 with brake, polyamide fork, grey non-marking rubber tread, stainless steel ball bearings, equipped with wire guards
• Internal runners: ABS rails for modules/drawers
