Linear-array ultrasound transducer SnG

Product description
The SnG ultrasound applicator is a hands-free accessory with a large front surface (17.3 cm² or 34.6 cm² depending on operating mode). It is intended for classical therapeutic ultrasound, phonophoresis, LIPUS therapy and combined protocols with electrotherapy. The applicator supports single-, dual- and quadruple-transducer operation to adapt treatment coverage to clinical needs.

Features

• Product code: A-AS-AST-SNG
• LIPUS mode
• Single-transducer operation option (classical ultrasound)
• Dual-transducer operation using transducer switching and ultrasonic wave modulation
• Quadruple-transducer operation (two-head, dual-section)
• Water resistance: IPX7
• Emission modes: continuous / pulse
• No contact detection
• Ultrasound head temperature control
• Ultrasound head sensitivity calibration
• Hook-and-loop belts for easy fixation to the patient

Ultrasound therapy technical parameters
acoustic working frequency: 1 MHz, 3 MHz
switch mode frequency: 1/3 MHz (switching every 8 s)
LIPUS mode frequency: 1 MHz
effective radiation area of one head: 2 x 3 cm²
total front area (one head): 17.3 cm²
total front area (two heads): 34.6 cm²

General technical parameters
accessory dimensions (without connection cable): 6.8 x 2.8 x 13 cm
weight: max 0.5 kg

Compatible with

• PhysioGo.Lite SONO
• PhysioGo.Lite COMBO

Technical specifications

• Acoustic working frequency: 1 MHz, 3 MHz
• Switch mode frequency: 1/3 MHz (switching every 8 s)
• LIPUS mode frequency: 1 MHz
• Effective radiation area of one head: 2 x 3 cm²
• Total front area (one head): 17.3 cm²
• Total front area (two heads): 34.6 cm²
• Accessory dimensions (without connection cable): 6.8 x 2.8 x 13 cm
• Weight: max 0.5 kg
• Product code: A-AS-AST-SNG
• Water resistance: IPX7
• Emission modes: continuous / pulse
• Contact detection: not present
• Temperature control: present for ultrasound head
• Sensitivity calibration: present for ultrasound head
• Strapping: hook-and-loop belts included
