Vaccine refrigerator TCW 120 AC

harsh environmentselectriccombination

Product overview
Vaccine refrigerator & ice-pack freezer with 153 L gross volume (refrigerator) and 28 L gross volume (freezer). Designed for stable storage of vaccines and ice-packs at designated set points.

Key specifications

• Set temperature: -20°C (freezer) | +5°C (refrigerator)
• Vaccine storage capacity: 120 L
• Certifications: EU MDR Class I | IEC 61000-3-2 / 61000-3-3
• Freeze protection level: Grade A
• Climate class (ambient): Hot zone (+43°C)
• Energy source: AC (110-240 V)

Innovative technology

• Built-in automatic voltage stabilization (operates with input voltages from 90 to 290 V) with protective relay
• 5-year international warranty covering parts and labour
• Low power consumption and environmentally friendly refrigerant (R600a)

Resistance to harsh environment

• Engineered for operation in tropical and hot climates
• Rotomoulded polyethylene body: corrosion-free and impact resistant
• Humidity control design to prevent condensation inside the refrigerator

Safety and traceability

• High-performance insulation
• Silicone gaskets and lockable clasps for secure closure and restricted access
• Audio-visual alarm system with remote transmission
• Remote temperature monitoring solution included: data logger and digital platform (RTMD)

Product technical table
Gross volume: 153 L (refrigerator) | 28 L (freezer)
Vaccine storage capacity: 120 L
Set temperature: -20°C (freezer) | +5°C (refrigerator)
Climate class (ambient): Hot zone (+43°C)
Certifications: EU MDR Class I | IEC 61000-3-2 / 61000-3-3
External dimensions (HxWxD): 910 x 1620 x 790 mm
Net weight: 139 kg
Shipping weight: 188 kg
Frequency: 50-60 Hz
Supply voltage: 110-240 V AC (stabilization 90–290 V)
Refrigerant type: Natural R600a
Materials: Rotomoulded polyethylene
Remote monitoring: RTMD included (data logger + digital platform)
Cool down: 192 h at 43°C
Hold over time: 73 h 54 min at +43°C
Energy consumption (stable running): 1.55 kWh / 24 h at 43°C
Energy source: AC
Freeze protection level: Grade A
Product type: Vaccine refrigerator & ice-pack freezer

Technical characteristics

• Gross volume: 153 L (refrigerator) and 28 L (freezer)
• Vaccine storage capacity: 120 L
• Set temperatures: +5°C (refrigerator) / -20°C (freezer)
• Climate class: Hot zone (+43°C)
• Refrigerant: R600a (natural)
• Body material: Rotomoulded polyethylene
• External dimensions (HxWxD): 910 x 1620 x 790 mm
• Net weight: 139 kg — Shipping weight: 188 kg
• Frequency: 50-60 Hz — Supply voltage: 110-240 V AC (stabilization 90–290 V)
• Energy consumption: 1.55 kWh / 24 h (at 43°C)
• Cool down performance: 192 h at 43°C — Hold over time: 73 h 54 min at +43°C
• Freeze protection level: Grade A
• Safety features: high insulation, silicone gaskets, lockable clasps, audio-visual alarms and remote transmission
• Monitoring: data logger and remote digital platform (RTMD)
• Warranty: 5 years (parts and labour)
