Hardness tester for the pharmaceutical industry TFUT-3

Product overview
Brand: BIOBASE
Product origin: CHINA
Delivery time: Within 7 days
Supply capacity: Factory direct supply
The TFUT-3 is a four-function tablet testing instrument for hardness, friability/abrasion, disintegration and dissolution rate, designed for pharmaceutical QC and formulation R&D.

Key features

• Combined testing: hardness, friability/abrasion, disintegration and dissolution; also inspects clarity of injectables and bottled liquids.
• Fully automatic control: auto-detection, auto-diagnosis, auto-alarm, auto-display and auto-reset.
• Precise temperature control (±0.3°C) and programmable timing with automatic shutdown.
• High-precision control of cylinder rotation speed and counts; continuous hardness measurement with digital readout.
• Manual tablet feeding, motor-driven compression and cyclic test modes for batch workflows.
• Dissolution baskets and paddle rods manufactured in imported SUS316 stainless steel for corrosion resistance.

Technical parameters
Model: TFUT-3
Temperature range: (20~40°C) ±0.3°C
Speed range: (20~200 rpm) ±2 rpm
Automatic time range: (1~900 min) ±0.5 min
Stations of dissolution: 3
Paddle radial run-out: ±0.5 mm
Basket radial run-out: ±1.0 mm
Basket assemblies: 2
Nacelle back-and-forth frequency: (30~32) times/min
Nacelle back-and-forth range: (55±2) mm
Drum: 1 (inner size φ286×H39 mm)
Tablet fall height: 156 mm
Rotating speed: (25±1) times/min
Rotating count: (100±1) turns
Hardness range: (25~199) ±1 N
Diameter range: (3~40) mm
Power supply: AC110/220V ±10%, 50/60Hz
Dimensions (W×D×H) mm: 520×380×470
Packing size (W×D×H) mm: 700×440×680
Gross weight: 45 kg

Applications

• Quality control and R&D laboratories in pharmaceutical manufacturing.
• Formulation development, stability studies and release testing workflows.
