1-screen X-ray film viewer / white light
40 X 43 / 90 X 43 / 120 X 43 / 150 X 43

• Number of screens:

  1-screen

• Other characteristics:

  white light

X-ray film viewer high light intensity series

Stove enamelled steel structure thickness 0,8 mm.
Fire epoxy painting colour peel RAL 9010, upon structure cleaning treatment
Smelted opaline acrylic screen thickness 3 mm inserted into the structure
Neon tubes of 6.000°Kelvin (other type of tubes available on request)
Speed bipolar switches on the front
Upper and/or central pressing rolls film holding system
External fuses lagging type 5×20 (positioned on the bottom right side)
Feeding cable complete with plug and earth “Italian” type 180 long
Integrable with other optional devices like: lateral support for spot viewers and/or magnifying lens, trolley on wheels.
X-ray film viewer conforms to Directive 93/42/CEE – Medical Devices – Class 1
