Conical dental implant TR3

titaniumconicalinternal octagon

Overview
Tissue-level dental implant with an internal conical connection featuring an antirotational octagon and a 1.5 mm polished transgingival collar suitable for monophasic techniques.

Key Features

• Apex with helical coils to improve primary stability during insertion.
• 1.5 mm polished crown/transgingival portion for controlled soft-tissue management.
• Conical connection with internal antirotational octagon combining a sealing conical interface and mechanical stability for prosthetic components.

Diameters and Lengths
Available diameters Ø3.75, Ø4.25 and Ø4.75. Lengths: 6, 8, 10, 11.5 and 13 mm. The coronal polished portion supports monophasic (one-stage) surgical approaches.

Data Sheet
Morphology: Root shape
Connection: Conical with antirotational octagon
Positioning: Tissue Level
Platform Switching: No
Prosthetic Platform: Unique
Surface treatment: BWS®
Diameters: Ø3.75 – Ø4.25 – Ø4.75
Lengths: 6 – 8 – 10 – 11.5 – 13 mm

Clinical & Packaging Notes

• Osseodensification option: compatible with the Versah drilling protocol to compact bone and enhance primary stability and ridge expansion when indicated.
• Sterile packaging: implants supplied sterile; sterility maintained if packaging is intact and stored correctly.
• Smart surgical kit: single, shared surgical kit across implant lines (except one-piece line); drills with optional depth stops; kit configurable with or without depth stops; includes dedicated screwdrivers and a torque ratchet.

Technical Specifications

• Model / Line: TR3 IMPLANT LINE
• Positioning: Tissue Level
• Connection type: Conical with antirotational octagon
• Platform switching: No
• Prosthetic platform: Unique
• Surface treatment: BWS®
• Available diameters: Ø3.75, Ø4.25, Ø4.75
• Available lengths: 6, 8, 10, 11.5, 13 mm
• Polished transgingival portion: 1.5 mm
• Apex design: helical coils for improved insertion stability
• Compatible clinical protocol: Versah osseodensification drilling
• Packaging: sterile packaging to guarantee sterility if undamaged
