Ceiling-mounted surgical light Luminox 300

LEDfor operating rooms2-arm

Overview
The Luminox 300 ceiling-mounted single dome is designed for operating theatres and procedure rooms that require focused, high-intensity illumination. It delivers uniform, glare-controlled light with high colour fidelity to assist accurate tissue visualisation during surgery. The fixed-focus Luminox 300 head provides a compact footprint with reliable central illumination up to 100,000 lux at 1 m.

Key highlights

• Single ceiling dome for focused field coverage
• Luminox 300 compact head
• 100,000 lux maximum central illumination at 1 m
• Fixed focus with CRI > 90
• 60,000+ hour LED service life

Specifications
Max. Central illumination at 1 m: 100,000 lux
Light field diameter at 1 m (d10): 250 mm ± 10%
Light head diameter: 300 mm
Depth of illumination at 20% (L1+L2): 1300 mm
Depth of illumination at 60% (L1+L2): 800 mm
Correlated Color Temperature (CCT): 6500 K ± 500 K
Color Rendering Index (CRI): > 90
Power consumption: < 25 W
Focus Mode: Fixed
Dimming Range: 0 – 100 %
No. of LEDs: 12
LED Service Life: 60,000 hours
Supply Voltage: 230 V ±10%, 50 Hz ±5%
Power Supply Unit: 24 V DC ±10%, 4.2 A max
Operating Temperature: 5 °C - 40 °C
Humidity: 10% - 90%

Notes
Specifications apply to wall, ceiling and mobile versions of Luminox 300. All values conform to IEC 60601-2-41 and are subject to a general industrial tolerance ± 5%. Luminox 300 uses fixed focus. Custom development available for programme-specific mount and interface requirements.

Technical specifications

• Max. Central illumination at 1 m: 100,000 lux
• Light field diameter at 1 m (d10): 250 mm ± 10%
• Light head diameter: 300 mm
• Depth of illumination at 20% (L1+L2): 1300 mm
• Depth of illumination at 60% (L1+L2): 800 mm
• Correlated Color Temperature (CCT): 6500 K ± 500 K
• Color Rendering Index (CRI): > 90
• Power consumption: < 25 W
• Focus Mode: Fixed
• Dimming Range: 0 – 100 %
• No. of LEDs: 12
• LED Service Life: 60,000 hours
• Supply Voltage: 230 V ±10%, 50 Hz ±5%
• Power Supply Unit: 24 V DC ±10%, 4.2 A max
• Operating Temperature: 5 °C - 40 °C
• Humidity: 10% - 90%
