Cutting electrosurgical unit Cresta B

coagulationbipolar cuttingmonopolar cutting

Overview
Cresta B is a compact electrosurgical generator on the Cresta Digital keypad‑LED platform, providing one monopolar and one bipolar output with SafeTis tissue impedance feedback and ContactIQ return‑electrode monitoring. It operates at 450 kHz and includes a Program Manager for up to 100 profiles. Intended for cardiac, neuro and general procedures that do not require integrated vessel sealing or saline bipolar on the same generator.

Key highlights

• 7‑segment LED interface for simple parameter readout
• SafeTis tissue impedance feedback for consistent effect
• ContactIQ return‑electrode monitoring
• 450 kHz operating frequency for stable tissue response
• Program Manager with up to 100 configurable profiles
• Pure Cut: 300 W @ 500 Ω (maximum)

Specifications
Outputs: One Monopolar, One Bipolar
Display: 7‑segment LED
Vessel Sealer: N/A
Saline Bipolar: N/A
Pure Cut: 300 W
Bipolar Cut: 120 W
Ordering code: LF90120
Weight: <10 kg
Dimensions (W x D x H): 410 mm x 160 mm x 480 mm
Input supply: 230 V ± 10%, 50 Hz
Operating temperature: +10 °C to +40 °C
Operating relative humidity: 15% to 85% non‑condensing
Operating atmospheric pressure: 700 to 1060 millibars
Transport & storage temperature: -10 °C to +60 °C
Transport & storage humidity: 15% to 90%
Transport & storage pressure: 500 to 1060 millibars

Power modes
MONOPOLAR CUT / Pure Cut — Max Settings: 300; Vpk‑pk: 3100 V; Rated Load: 500 Ω; Max Power: 300 W; Crest Factor: 1.4
MONOPOLAR CUT / Blend 1 — Max Settings: 250; Vpk‑pk: 3300 V; Rated Load: 500 Ω; Max Power: 250 W; Crest Factor: 2.0
MONOPOLAR COAG / Spray — Max Settings: 80; Vpk‑pk: 6000 V; Rated Load: 300 Ω; Max Power: 80 W; Crest Factor: 6.5
BIPOLAR / Cut — Max Settings: 120; Vpk‑pk: 800 V @ 500 Ω; Rated Load: 100 Ω; Max Power: 120 W; Crest Factor: 1.4

Notes

• The ratings above are maximum values.
• All output power values may vary by ±20%; peak voltages and crest factors change accordingly.
• Surgeons can reduce power during procedures by selecting appropriate settings.
• Always use the lowest power that achieves the required surgical effect.

Technical specifications

• Product name: Cresta B
• Platform: Cresta Digital (keypad‑LED)
• Outputs: One Monopolar, One Bipolar
• Display type: 7‑segment LED
• Tissue feedback: SafeTis tissue impedance feedback
• Return‑electrode monitoring: ContactIQ
• Operating frequency: 450 kHz
• Program Manager: up to 100 profiles
• Pure Cut maximum: 300 W @ 500 Ω
• Bipolar Cut maximum: 120 W
• Ordering code: LF90120
• Weight: <10 kg
• Dimensions (W x D x H): 410 mm x 160 mm x 480 mm
• Input supply: 230 V ± 10%, 50 Hz
• Operating temperature: +10 °C to +40 °C
• Operating relative humidity: 15% to 85% non‑condensing
• Operating atmospheric pressure: 700 to 1060 millibars
• Transport & storage temperature: -10 °C to +60 °C
• Transport & storage humidity: 15% to 90%
• Transport & storage pressure: 500 to 1060 millibars
