USB video recorder and streamer Infini Pulse 2A

HDfull HDmulti 4K

Product overview
The Infini Pulse 2A is a 2-input recording and streaming unit designed for professional AV workflows. It provides dual 4K60 HDMI inputs with Single, PIP and PAP multiview layouts, integrated streaming software and a wireless microphone, plus a compact operator interface with a 7" touchscreen and a 24" FHD display.

Key highlights

• 2 × 4K60 HDMI inputs
• Single, PIP and PAP multiview
• 4K60 loop-out for monitoring
• Wireless microphone support
• Quad-core Cortex-A76 processor
• Infini Strima Mini streaming software
• Optional Infini OneView NAS (per project)
• 7" touchscreen + 24" FHD secondary display
• Order code: LF90355

Technical specifications

• Model: Infini Pulse 2A
• Function: 2-input recording and streaming with wireless microphone
• Processor: Quad-core Cortex-A76
• Streaming software: Infini Strima Mini
• Optional NAS software: Infini OneView (by project need)
• HDMI inputs: 2 × 4K60
• HDMI output (loop-out): 1 × 4K60
• Multiview modes: Single, PIP, PAP
• Audio: Wireless microphone

Connectivity & storage

• Interfaces: USB 3.0 (Type A), RJ45
• Recording format: MPEG‑4 (H.264/H.265 + AAC)
• Recording resolution: 1080p
• Streaming resolutions: 4K60 and 1080p60
• Storage: USB 2.0 HDD support and NAS (Infini OneView optional)

Ordering & options

• Order code: LF90355
• Optional: Infini OneView NAS deployment according to project needs
