Built-in lighting Hexa Ring

pendantceiling-mountedfor clinic

Presentation
Hexagonal LED suspended luminaire with an open, architectural profile designed for receptions, waiting areas, offices and premium spaces. The graphic hexagonal ring creates a strong visual identity and delivers uniform, elegant light through an opal diffuser.

Key points

• Open hexagonal ring shape for an airy, structuring appearance.
• Opal diffuser for homogeneous light suitable for professional environments.
• Aluminium 6063 profile with opal diffuser.
• Advanced control options: DALI, DALI DT6, DALI DT8, 0-10V, Triac, ON/OFF.
• Drivers available: BOKE, Cupower.
• Luminaire warranty: 5 years.
• Installation modes: suspended, surface-mounted ceiling or recessed (installation optional).

Recommended applications

• Waiting room
• Reception area
• Premium office
• Design care space
• Clinic or medical center
• Architectural projects

Available finishes

• White
• Silver
• Black
• Gold (premium)

Options and customization

• Colour temperatures: 3000K / 4000K / 6000K / customizable 3000–6000K.
• Control modes: 0-10V, DALI, DT6, DT8, Triac, ON/OFF.
• Available sizes: from 900 × 780 mm to 3600 × 3117 mm.
• Power range: 54W to 216W.
• Luminous flux: 5,400 lm to 21,600 lm.
• Ingress protection: IP20.
• Power factor: 0.95.
• Flicker-free operation.

Integration in a project (process)

• Send plans and dimensions / identify zones to equip.
• Analyze layout, ceiling height and venue identity.
• Propose configuration (size, finish, control mode).
• Prepare per-luminaire costing, delivery and optional installation.

Technical characteristics / specifications

• Type: Hexagonal LED suspended luminaire — open design with architectural profile.
• Profile: Aluminium 6063 with opal diffuser.
• Profile dimensions: W60 × H80 mm.
• Power supply: AC100-277V / AC220-240V, 50/60Hz.
• LED: SANAN SMD2835.
• Drivers: BOKE / Cupower.
• Colour temperatures: 3000K / 4000K / 6000K / 3000–6000K customizable.
• CRI: 80Ra.
• Power factor: 0.95.
• Operation: Flicker-free.
• Beam angle: 120°.
• Control modes: ON/OFF, 0-10V, DALI, DALI DT6, DALI DT8, Triac dimming.
• Installation: Suspended, surface-mounted ceiling or recessed — installation optional.
• Finishes: Black, white, gold, silver.
• Available sizes: 900 × 780 mm to 3600 × 3117 mm.
• Powers: 54W to 216W.
• Luminous flux: 5,400 lm to 21,600 lm.
• Ingress protection: IP20.
• Luminaire warranty: 5 years.
• Indicative price: From €2,000 excl. VAT (depending on configuration).
• Delivery: Europe (priced per project).
